Short description
๐๐ Move all AutoCAD XREF block references onto clean XREF layers using either one shared _XREF layer or individual 0-XREF_ layers.
Command:
๐ Primary command: XRefs2LayersOptions
๐ Option 1: XRefsTo_Xref / X2_XREF โ moves all detected XREF inserts to one layer named _XREF.
๐ Option 2: XRefsToLayers / X2L โ moves each XREF insert to its own layer using the 0-XREF_ prefix.
๐ช Dialog helper: radioX2LDCL creates a small DCL option dialog for choosing the workflow.
Description:
๐ XRefs2Layers is an AutoCAD AutoLISP utility for organizing external reference inserts by layer.
๐ The tool scans the current drawing for XREF block definitions, ignores names matching *TBLOCK*, finds matching INSERT references, and moves those references to controlled XREF layers.
๐งญ The user can run a dialog-based workflow with XRefs2LayersOptions or run direct commands for a specific mode. One mode places every XREF on a shared _XREF layer, while the other mode creates separate 0-XREF_ layers for clearer drawing management.
๐ก๏ธ The routine uses ActiveX layer handling, undo marks, locked-layer recovery logic, and a final alert report showing how many XREFs were moved to each target layer.
Helper function: (if any)โ
๐ช writeX2LDCL โ writes the temporary DCL dialog for the two XREF layer options.
๐ radioX2LDCL โ loads the DCL, remembers the last selected option, and returns the selected workflow.
๐งญ XRefs2LayersOptions โ main option selector that launches the selected XREF layer command.
๐ XRefsToLayers / X2L โ creates or uses 0-XREF_ layers and moves each XREF to its matching named layer.
๐ XRefsTo_Xref / X2_XREF โ creates or uses the shared _XREF layer and moves all XREF inserts there.
๐ก๏ธ Error handlers โ close undo marks safely and report unexpected errors without interrupting normal cancel behavior.
Functionalities:
๐ XREF detection โ scans AutoCAD Blocks collection for definitions where IsXRef is true.
๐งน TBLOCK exclusion โ skips XREF names matching *TBLOCK* to avoid processing title-block style references.
๐ช DCL option dialog โ provides a simple radio-button interface for choosing the layer organization mode.
๐ Per-XREF layer mode โ moves XREF inserts to uppercase layers named with the 0-XREF_ prefix.
๐ฆ Shared layer mode โ moves all XREF inserts to one standard _XREF layer.
๐งฑ Layer auto-create โ creates missing destination layers automatically.
๐ Locked-layer handling โ temporarily unlocks the current layer when required so the XREF can be moved.
โฉ๏ธ Undo mark support โ wraps processing in an undo mark for safer drawing edits.
๐ Move report โ displays a summary alert showing counts by target layer.
โ๏ธ Session memory โ remembers the last selected radio option during the active AutoCAD session.
๐ซ Zero-XREF warning โ alerts the user when no XREFs are found in the drawing.
Result:
โ The result is a cleaner AutoCAD drawing where XREF references are organized on predictable layers.
๐ CAD teams can quickly isolate, freeze, lock, audit, or plot XREF content by using either one shared _XREF layer or separate 0-XREF_ layers.
๐ The final alert gives immediate feedback about how many XREF references were moved to each layer.
