<ResourceDictionary
xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
xmlns:src="clr-namespace:Autodesk.Windows;assembly=AdWindows">

<src:RibbonToolTip x:Key="LispLoaderExtra">
<src:RibbonToolTip.ExpandedContent>
<StackPanel>
<TextBlock Background="AntiqueWhite" TextAlignment="Left">
<Bold>Function Syntax: LISPLOADEXTRA / LISPLOADREPORT / LISPLOADDIAG</Bold>
<LineBreak/>
<Bold>Version: 1.0 Date: 25.06.2026 8:46:25AM</Bold>
<LineBreak/>
<Bold>Version: 1.0 Date: 11.08.2026 3:38:21PM</Bold>
<LineBreak/>
<Hyperlink>N/A</Hyperlink>

<Bold><Run Foreground="DodgerBlue">Description</Run></Bold><LineBreak/>
<Run Foreground="White">🧩 LispLoaderExtra v1.5.000 is a modeless AutoCAD and Civil 3D .NET loader for scanning filtering selecting loading and reloading LSP VLX FAS and DLL files from a structured CAD tool library.</Run><LineBreak/>
<Run Foreground="White">🎛️ The plugin provides a dark themed WinForms interface with category and name filters search checkboxes status columns a live log pane and load controls.</Run><LineBreak/>
<Run Foreground="White">🛡️ Files are loaded through the AutoCAD application context with isolated results so one failed tool does not have to stop the rest of the selected load sequence.</Run><LineBreak/>
<Bold><Run Foreground="DodgerBlue">Function Syntax</Run></Bold><LineBreak/>
<Run Foreground="White">Main window: </Run><Bold><Run Foreground="Orange">LISPLOADEXTRA</Run></Bold><LineBreak/>
<Run Foreground="White">Last session report: </Run><Bold><Run Foreground="Orange">LISPLOADREPORT</Run></Bold><LineBreak/>
<Run Foreground="White">Loader diagnostics: </Run><Bold><Run Foreground="Orange">LISPLOADDIAG</Run></Bold><LineBreak/>
<Bold><Run Foreground="LimeGreen">Primary Workflow</Run></Bold><LineBreak/>
<Run Foreground="White">1. NETLOAD the compiled LispLoaderExtra DLL into AutoCAD.</Run><LineBreak/>
<Run Foreground="White">2. Run LISPLOADEXTRA to open the modeless loader window.</Run><LineBreak/>
<Run Foreground="White">3. The application scans the configured Help_File tree for supported program files.</Run><LineBreak/>
<Run Foreground="White">4. Filter by AutoCAD or Civil 3D category name or free text and check the files that should be processed.</Run><LineBreak/>
<Run Foreground="White">5. Use Load Reload or Load Selected to process the required files.</Run><LineBreak/>
<Run Foreground="White">6. Review per row status version information and the live color coded log.</Run><LineBreak/>
<Run Foreground="White">7. Use LISPLOADREPORT to review last session results or LISPLOADDIAG when loader API diagnostics are required.</Run><LineBreak/>
<Bold><Run Foreground="LimeGreen">Functionalities</Run></Bold><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Multi format scanning</Run></Bold><Run Foreground="White"> - discovers LSP VLX FAS and DLL files in the structured source tree.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Modeless loader window</Run></Bold><Run Foreground="White"> - stays usable while AutoCAD remains active.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Category and name filters</Run></Bold><Run Foreground="White"> - narrows the displayed tool collection.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Text search</Run></Bold><Run Foreground="White"> - filters visible loader rows by search text.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Checkbox selection</Run></Bold><Run Foreground="White"> - supports selective loading and Select All or None actions.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Load and reload actions</Run></Bold><Run Foreground="White"> - process checked files or force reload the chosen set.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Load Selected</Run></Bold><Run Foreground="White"> - loads highlighted grid rows and is also available through F3.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Persistent checked state</Run></Bold><Run Foreground="White"> - stores checked file paths in ss checked.json between sessions.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Automatic disk rescan</Run></Bold><Run Foreground="White"> - uses FileSystemWatcher with debounce when supported files change.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Right click tools</Run></Bold><Run Foreground="White"> - provides load reload open folder open editor copy path and checkbox actions.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Editor integration</Run></Bold><Run Foreground="White"> - opens source files in Notepad++ with a Notepad fallback.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Live log panel</Run></Bold><Run Foreground="White"> - shows real time color coded loading messages with Store Log Clear and Auto Scroll.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Status change flash</Run></Bold><Run Foreground="White"> - briefly highlights rows whose load status changed.</Run><LineBreak/>
<Run Foreground="White">✅ </Run><Bold><Run Foreground="LimeGreen">Diagnostics command</Run></Bold><Run Foreground="White"> - searches loaded AutoCAD assemblies for LISP related invocation methods.</Run><LineBreak/>
<Bold><Run Foreground="DarkRed">Important Notes</Run></Bold><LineBreak/>
<Run Foreground="White">⚠️ </Run><Bold><Run Foreground="DarkRed">Project version is 1.5.000.</Run></Bold><LineBreak/>
<Run Foreground="White">⚠️ </Run><Bold><Run Foreground="DarkRed">LISP VLX and FAS loading uses SendStringToExecute first then acedInvoke and reflection fallback strategies.</Run></Bold><LineBreak/>
<Run Foreground="White">⚠️ </Run><Bold><Run Foreground="DarkRed">A 30 second per file timeout is used by the current FileLoader implementation.</Run></Bold><LineBreak/>
<Run Foreground="White">⚠️ </Run><Bold><Run Foreground="DarkRed">DLL loading uses Assembly.LoadFrom and AutoCAD ExtensionLoader.</Run></Bold><LineBreak/>
<Run Foreground="White">⚠️ </Run><Bold><Run Foreground="DarkRed">Escape is swallowed by the modeless window to avoid passing the key into the AutoCAD viewport.</Run></Bold><LineBreak/>
<Bold><Run Foreground="Yellow">SEO Keywords</Run></Bold><LineBreak/>
<Run Foreground="Yellow">🏷️ AutoCAD  🏷️ Civil 3D  🏷️ LispLoaderExtra  🏷️ AutoLISP loader  🏷️ VLX loader  🏷️ FAS loader  🏷️ DLL loader  🏷️ NETLOAD  🏷️ WinForms  🏷️ FileSystemWatcher  🏷️ LISPLOADREPORT  🏷️ LISPLOADDIAG  🏷️ CAD automation  🏷️ Plugin manager</Run><LineBreak/>
</TextBlock>

<Grid>
<Image Source="Image_000.png" Stretch="Uniform"/>
</Grid>

</StackPanel>
</src:RibbonToolTip.ExpandedContent>
</src:RibbonToolTip>
</ResourceDictionary>

// ===== FILE: DiskScanner.cs =====
using System;
using System.Collections.Generic;
using System.IO;
using System.Linq;

namespace LispLoaderExtra
{
    /// <summary>
    /// Scans the Help_File folder tree and returns ScannedFile entries.
    ///
    /// Structure:
    ///   AutoCAD:  Help_File\{MenuFolder}\{SubFolder}\*.{lsp,vlx,fas,dll}
    ///             MenuFolder must contain "_menu" in its name (case-insensitive)
    ///             SubFolder is one level deep inside the _menu folder
    ///             Files directly inside SubFolder are collected (no deeper recursion)
    ///
    ///   Civil 3D: Help_File\C3D\{C3D_*_menu}\{SubFolder}\*.{lsp,vlx,fas,dll}
    ///             Display name strips the "C3D_" prefix: C3D_Alignment_menu → Alignment_menu
    ///
    /// Exclusions (applied to every path segment below the base):
    ///   - Exact names (case-insensitive): ss, vlx_dll, vlx_fas, lispsloader
    ///   - Names starting with those tokens + "_" or "-" (e.g. ss_01, vlx_fas_2)
    ///   - Names starting with "@"
    ///
    /// Improvements over previous version:
    ///   - All string comparisons use net48-compatible overloads (no StringComparison on Contains)
    ///   - Split uses char[] instead of two-arg char overload (net48 compat)
    ///   - Results sorted: AutoCAD first, then Civil 3D; alphabetically within each group
    ///   - SafeGetDirectories / SafeGetFiles log errors instead of swallowing silently
    /// </summary>
    internal static class DiskScanner
    {
        internal static readonly string BaseFolder =
            @"C:\Users\mateid\OneDrive - DB E.C.O. Group\@C3D\@Dan_Templates\Acad\Support_files\Lisps\Help_File";

        private static readonly string C3DFolder =
            Path.Combine(BaseFolder, "C3D");

        private static readonly HashSet<string> ExcludedNames =
            new HashSet<string>(StringComparer.OrdinalIgnoreCase)
            { "ss", "vlx_dll", "vlx_fas", "lispsloader", "lispploaderextra" };

        private static readonly HashSet<string> SupportedExtensions =
            new HashSet<string>(StringComparer.OrdinalIgnoreCase)
            { ".lsp", ".vlx", ".fas", ".dll" };

        private static readonly char[] PathSeps = new char[] { '\\', '/' };

        // ── Public API ────────────────────────────────────────────────────────

        internal static List<ScannedFile> Scan()
        {
            var results = new List<ScannedFile>();
            if (!Directory.Exists(BaseFolder))
            {
                LogManager.Warn("DiskScanner", $"Base folder not found: {BaseFolder}");
                return results;
            }

            ScanAutoCAD(results);
            ScanC3D(results);

            // Sort: category first, then menu name, then file name
            results.Sort((a, b) =>
            {
                int c = string.Compare(a.Category, b.Category, StringComparison.OrdinalIgnoreCase);
                if (c != 0) return c;
                c = string.Compare(a.MenuName, b.MenuName, StringComparison.OrdinalIgnoreCase);
                if (c != 0) return c;
                return string.Compare(a.FileName, b.FileName, StringComparison.OrdinalIgnoreCase);
            });

            // Assign sequential row numbers after sort
            for (int i = 0; i < results.Count; i++)
                results[i].RowIndex = i + 1;

            LogManager.Info("DiskScanner",
                $"Scan complete: {results.Count} files " +
                $"(AutoCAD: {results.Count(f => f.Category == "AutoCAD")}, " +
                $"Civil 3D: {results.Count(f => f.Category == "Civil 3D")})");

            return results;
        }

        /// <summary>Returns distinct sorted menu names for the given category.</summary>
        internal static List<string> GetMenuNames(string category, List<ScannedFile> files)
        {
            return files
                .Where(f => category == "All" ||
                            string.Equals(f.Category, category, StringComparison.OrdinalIgnoreCase))
                .Select(f => f.MenuName)
                .Distinct(StringComparer.OrdinalIgnoreCase)
                .OrderBy(n => n, StringComparer.OrdinalIgnoreCase)
                .ToList();
        }

        // ── AutoCAD scan ──────────────────────────────────────────────────────
        // Pattern: Help_File \ {*_menu folder} \ {sub-folder} \ {files}

        private static void ScanAutoCAD(List<ScannedFile> results)
        {
            foreach (string menuDir in SafeGetDirectories(BaseFolder))
            {
                string menuName = Path.GetFileName(menuDir);

                // Must contain "_menu" — net48: use IndexOf, not Contains(str, comparison)
                if (menuName.IndexOf("_menu", StringComparison.OrdinalIgnoreCase) < 0) continue;
                if (string.Equals(menuName, "C3D", StringComparison.OrdinalIgnoreCase)) continue;
                if (IsExcluded(menuName)) continue;

                foreach (string subDir in SafeGetDirectories(menuDir))
                {
                    if (IsExcluded(Path.GetFileName(subDir))) continue;

                    foreach (string file in SafeGetFiles(subDir))
                    {
                        string ext = Path.GetExtension(file);
                        if (!SupportedExtensions.Contains(ext)) continue;
                        if (IsExcludedPath(file))               continue;

                        results.Add(new ScannedFile(
                            category:  "AutoCAD",
                            menuName:  menuName,
                            fileName:  Path.GetFileName(file),
                            extension: ext,
                            fullPath:  file));
                    }
                }
            }
        }

        // ── Civil 3D scan ─────────────────────────────────────────────────────
        // Pattern: Help_File \ C3D \ {C3D_*_menu folder} \ {sub-folder} \ {files}

        private static void ScanC3D(List<ScannedFile> results)
        {
            if (!Directory.Exists(C3DFolder)) return;

            foreach (string menuDir in SafeGetDirectories(C3DFolder))
            {
                string menuName = Path.GetFileName(menuDir);
                if (menuName.IndexOf("_menu", StringComparison.OrdinalIgnoreCase) < 0) continue;
                if (IsExcluded(menuName)) continue;

                // Strip "C3D_" prefix for display: C3D_Alignment_menu → Alignment_menu
                string displayName = menuName.StartsWith("C3D_", StringComparison.OrdinalIgnoreCase)
                    ? menuName.Substring(4)
                    : menuName;

                foreach (string subDir in SafeGetDirectories(menuDir))
                {
                    if (IsExcluded(Path.GetFileName(subDir))) continue;

                    foreach (string file in SafeGetFiles(subDir))
                    {
                        string ext = Path.GetExtension(file);
                        if (!SupportedExtensions.Contains(ext)) continue;
                        if (IsExcludedPath(file))               continue;

                        results.Add(new ScannedFile(
                            category:  "Civil 3D",
                            menuName:  displayName,
                            fileName:  Path.GetFileName(file),
                            extension: ext,
                            fullPath:  file));
                    }
                }
            }
        }

        // ── Exclusion helpers ─────────────────────────────────────────────────

        private static bool IsExcluded(string folderName)
        {
            if (string.IsNullOrEmpty(folderName)) return false;
            if (folderName.StartsWith("@"))        return true;

            string low = folderName.ToLowerInvariant();
            foreach (string ex in ExcludedNames)
            {
                string exl = ex.ToLowerInvariant();
                if (low == exl ||
                    low.StartsWith(exl + "_", StringComparison.Ordinal) ||
                    low.StartsWith(exl + "-", StringComparison.Ordinal))
                    return true;
            }
            return false;
        }

        private static bool IsExcludedPath(string fullPath)
        {
            if (fullPath.Length <= BaseFolder.Length) return false;

            string rel = fullPath.Substring(BaseFolder.Length).TrimStart(PathSeps);

            // net48: Split(char[]) — not Split(char, char)
            foreach (string part in rel.Split(PathSeps))
            {
                if (IsExcluded(part)) return true;
            }
            return false;
        }

        // ── Safe I/O ─────────────────────────────────────────────────────────

        private static string[] SafeGetDirectories(string path)
        {
            try   { return Directory.GetDirectories(path); }
            catch (System.Exception ex)
            {
                LogManager.Warn("DiskScanner", $"Cannot read directories: {path} — {ex.Message}");
                return new string[0];
            }
        }

        private static string[] SafeGetFiles(string path)
        {
            try   { return Directory.GetFiles(path); }
            catch (System.Exception ex)
            {
                LogManager.Warn("DiskScanner", $"Cannot read files: {path} — {ex.Message}");
                return new string[0];
            }
        }
    }
}


// ===== FILE: LoadSession.cs =====
using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;

namespace LispLoaderExtra
{
    /// <summary>
    /// Collects all LoadResult entries for one plugin-load session.
    /// Provides summary statistics and formatted report text.
    /// Singleton — one session per AutoCAD load.
    /// </summary>
    internal static class LoadSession
    {
        private static readonly List<LoadResult> _results = new List<LoadResult>();
        private static DateTime _startTime;

        internal static IReadOnlyList<LoadResult> Results => _results.AsReadOnly();

        internal static void Begin()
        {
            _results.Clear();
            _startTime = DateTime.Now;
        }

        internal static void Add(LoadResult r)
        {
            _results.Add(r);
            // Mirror to log
            switch (r.Status)
            {
                case LoadStatus.OK:
                    if (r.Extension == ".dll" && !string.IsNullOrEmpty(r.ErrorMessage))
                    {
                        // DLL OK — ErrorMessage carries the version stamp
                        LogManager.Info("FileLoader",
                            $"[OK-DLL]  {r.FileName}  v{r.ErrorMessage}  ({r.Duration.TotalMilliseconds:0}ms)");
                        LogManager.Info("FileLoader", $"         {r.Path}");
                    }
                    else
                    {
                        LogManager.Info("FileLoader",
                            $"[OK-{r.TypeLabel,-3}]  {r.FileName}  ({r.Duration.TotalMilliseconds:0}ms)");
                        LogManager.Info("FileLoader", $"         {r.Path}");
                    }
                    break;
                case LoadStatus.Failed:
                    LogManager.Error("FileLoader", $"[FAIL-{r.TypeLabel,-3}] {r.FileName}");
                    LogManager.Error("FileLoader", $"         {r.ErrorMessage}");
                    LogManager.Error("FileLoader", $"         {r.Path}");
                    break;
                case LoadStatus.NotFound:
                    LogManager.Warn("FileLoader", $"[MISSING]  {r.Path}");
                    break;
                case LoadStatus.Skipped:
                    LogManager.Warn("FileLoader", $"[SKIP]     {r.Path}  (unsupported type)");
                    break;
            }
        }

        // ── Stats ─────────────────────────────────────────────────────────────

        internal static int TotalCount    => _results.Count;
        internal static int OkCount       => _results.Count(r => r.Status == LoadStatus.OK);
        internal static int FailCount     => _results.Count(r => r.Status == LoadStatus.Failed);
        internal static int NotFoundCount => _results.Count(r => r.Status == LoadStatus.NotFound);
        internal static int SkipCount     => _results.Count(r => r.Status == LoadStatus.Skipped);

        internal static int CountByType(string ext) =>
            _results.Count(r => r.Extension == ext && r.Status == LoadStatus.OK);

        internal static TimeSpan TotalDuration => DateTime.Now - _startTime;

        // ── Summary line (for command line) ───────────────────────────────────

        internal static string SummaryLine =>
            $"Load complete — " +
            $"OK: {OkCount}  " +
            $"FAILED: {FailCount}  " +
            $"NOT FOUND: {NotFoundCount}  " +
            $"SKIPPED: {SkipCount}  " +
            $"| {TotalDuration.TotalSeconds:0.0}s total";

        // ── Full text report (for clipboard / log) ────────────────────────────

        internal static string BuildTextReport()
        {
            var sb = new StringBuilder();
            string line = new string('─', 72);

            sb.AppendLine(line);
            sb.AppendLine($"  LispLoaderExtra — Load Report");
            sb.AppendLine($"  {DateTime.Now:dd.MM.yyyy  HH:mm:ss}");
            sb.AppendLine(line);
            sb.AppendLine($"  Total files:  {TotalCount}");
            sb.AppendLine($"  OK:           {OkCount}  " +
                          $"(LSP:{CountByType(".lsp")}  " +
                          $"VLX:{CountByType(".vlx")}  " +
                          $"FAS:{CountByType(".fas")}  " +
                          $"DLL:{CountByType(".dll")})");
            sb.AppendLine($"  Failed:       {FailCount}");
            sb.AppendLine($"  Not found:    {NotFoundCount}");
            sb.AppendLine($"  Skipped:      {SkipCount}");
            sb.AppendLine($"  Total time:   {TotalDuration.TotalSeconds:0.00}s");
            sb.AppendLine(line);

            // Errors first
            var errors = _results.Where(r => r.Status == LoadStatus.Failed).ToList();
            if (errors.Count > 0)
            {
                sb.AppendLine("  ERRORS:");
                foreach (var r in errors)
                {
                    sb.AppendLine($"    [{r.TypeLabel}] {r.FileName}");
                    sb.AppendLine($"           {r.Path}");
                    sb.AppendLine($"           {r.ErrorMessage}");
                }
                sb.AppendLine(line);
            }

            var missing = _results.Where(r => r.Status == LoadStatus.NotFound).ToList();
            if (missing.Count > 0)
            {
                sb.AppendLine("  NOT FOUND:");
                foreach (var r in missing)
                    sb.AppendLine($"    {r.Path}");
                sb.AppendLine(line);
            }

            sb.AppendLine("  ALL FILES:");
            foreach (var r in _results)
            {
                string status = r.Status switch {
                    LoadStatus.OK       => "OK     ",
                    LoadStatus.Failed   => "FAIL   ",
                    LoadStatus.NotFound => "MISSING",
                    LoadStatus.Skipped  => "SKIP   ",
                    _                   => "???????",
                };
                string extra = (r.Extension == ".dll" && r.Status == LoadStatus.OK && !string.IsNullOrEmpty(r.ErrorMessage))
                    ? $"  v{r.ErrorMessage}"
                    : "";
                sb.AppendLine($"    {status}  [{r.TypeLabel,-3}]  {r.FileName}  ({r.Duration.TotalMilliseconds:0}ms){extra}");
            }
            sb.AppendLine(line);

            return sb.ToString();
        }
    }
}


// ===== FILE: ConfigReader.cs =====
using System;
using System.Collections.Generic;
using System.IO;

namespace LispLoaderExtra
{
    internal static class ConfigReader
    {
        private const string Source = "ConfigReader";

        // Base folder for resolving relative paths listed in the config
        internal static readonly string BaseFolder =
            @"C:\Users\mateid\OneDrive - DB E.C.O. Group\@C3D\@Dan_Templates\Acad\Support_files\Lisps\Help_File";

        // Config file lives next to the log in the ss\ folder
        internal static readonly string ConfigFile =
            Path.Combine(LogManager.LogFolder, "LoaderConfig.txt");

        internal static IReadOnlyList<string> ReadPaths()
        {
            LogManager.Info(Source, $"Looking for config: {ConfigFile}");

            if (!File.Exists(ConfigFile))
            {
                LogManager.Error(Source, $"Config not found: {ConfigFile}");
                return Array.Empty<string>();
            }

            var paths = new List<string>();

            try
            {
                foreach (string raw in File.ReadAllLines(ConfigFile))
                {
                    string line = raw.Trim();
                    if (string.IsNullOrEmpty(line)) continue;
                    if (line.StartsWith("#"))        continue;
                    if (line.StartsWith(";"))        continue;

                    string resolved = Path.IsPathRooted(line)
                        ? line
                        : Path.Combine(BaseFolder, line);

                    paths.Add(resolved);
                }

                LogManager.Info(Source, $"Config loaded — {paths.Count} entries");
            }
            catch (System.Exception ex)
            {
                LogManager.Error(Source, $"Failed to read config: {ex.Message}");
            }

            return paths;
        }
    }
}


// ===== FILE: LoadResult.cs =====
using System;

namespace LispLoaderExtra
{
    /// <summary>
    /// The outcome of attempting to load a single file.
    /// </summary>
    internal enum LoadStatus
    {
        OK,         // loaded successfully
        Failed,     // file exists but load threw an error
        NotFound,   // file path does not exist on disk
        Skipped,    // unsupported extension
    }

    /// <summary>
    /// Immutable record of one file-load attempt.
    /// </summary>
    internal sealed class LoadResult
    {
        internal string     Path        { get; }
        internal string     Extension   { get; }   // .lsp / .vlx / .fas / .dll
        internal LoadStatus Status      { get; }
        internal string     ErrorMessage{ get; }   // empty string when OK
        internal TimeSpan   Duration    { get; }
        internal DateTime   Timestamp   { get; }

        internal LoadResult(
            string     path,
            string     extension,
            LoadStatus status,
            string     errorMessage,
            TimeSpan   duration)
        {
            Path         = path;
            Extension    = extension.ToLowerInvariant();
            Status       = status;
            ErrorMessage = errorMessage ?? string.Empty;
            Duration     = duration;
            Timestamp    = DateTime.Now;
        }

        // Convenience helpers
        internal string FileName   => System.IO.Path.GetFileName(Path);
        internal string TypeLabel  => Extension.TrimStart('.').ToUpperInvariant();   // LSP / VLX / FAS / DLL
        internal bool   IsOk       => Status == LoadStatus.OK;
        internal bool   HasError   => Status == LoadStatus.Failed;
    }
}


// ===== FILE: FileLoader.cs =====
// Alias System.Exception explicitly to avoid ambiguity with
// Autodesk.AutoCAD.Runtime.Exception which lives in the same namespace.
using SysEx = System.Exception;

using System;
using System.Diagnostics;
using System.IO;
using System.Reflection;
using System.Runtime.InteropServices;
using System.Threading;
using Autodesk.AutoCAD.ApplicationServices;
using Autodesk.AutoCAD.DatabaseServices;
using Autodesk.AutoCAD.Runtime;

namespace LispLoaderExtra
{
    /// <summary>
    /// Loads .lsp / .vlx / .fas / .dll files safely from ANY thread.
    ///
    /// THREAD-SAFETY — ROOT CAUSE OF v1.3 ACCESS VIOLATION
    /// ─────────────────────────────────────────────────────
    /// acedInvoke (P/Invoke into accore.dll) and ExtensionLoader.Load
    /// MUST run on AutoCAD's document-context thread.  In v1.3 the form is
    /// modeless (Show, not ShowDialog), so Load() was called from the WinForms
    /// UI thread → Access Violation at 96AFEB62h.
    ///
    /// FIX — ExecuteInApplicationContext
    /// ──────────────────────────────────
    /// Every load is posted to AutoCAD's own thread via:
    ///   Application.DocumentManager.ExecuteInApplicationContext(cb, null)
    /// A ManualResetEventSlim lets the UI thread block until the result is
    /// ready (30 s timeout) while the form remains repaint-responsive.
    ///
    /// LISP LOAD STRATEGIES (tried in order on the ACAD thread):
    ///   A. Document.SendStringToExecute("(load \"/path\")\n", false, false, false)
    ///      Safest: injects LISP into AutoCAD's own command evaluator.
    ///      Signature: (string commandString, bool activate, bool wrapUpInactiveDoc,
    ///                  bool echoCommand) — no 'wrap' named param.
    ///   B. acedInvoke P/Invoke from accore.dll
    ///   C. Reflection scan for acedInvoke in acmgd / accoremgd
    ///
    /// DLL LOAD:
    ///   Assembly.LoadFrom + ExtensionLoader.Load on ACAD thread.
    ///   Version stamp: "major.minor.build_[dd.mm.yyyy_hh.mm.ss]" (file creation time).
    /// </summary>
    internal static class FileLoader
    {
        // ── resbuf type codes ─────────────────────────────────────────────────
        private const short RTSTR = 5005;
        private const short RTLB  = 5016;
        private const short RTLE  = 5017;

        // ── P/Invoke — only safe on ACAD application-context thread ──────────
        [DllImport("accore.dll",
            CallingConvention = CallingConvention.Cdecl,
            EntryPoint = "acedInvoke")]
        private static extern int AcedInvoke(IntPtr args, out IntPtr result);

        private static bool _pinvokeAvailable = true;

        // ── Reflection cache ──────────────────────────────────────────────────
        private static MethodInfo? _reflectMethod;
        private static bool        _reflectSearched;
        private static readonly object _reflectLock = new object();

        // ═════════════════════════════════════════════════════════════════════
        // PUBLIC ENTRY — safe to call from any thread (UI, background, etc.)
        // ═════════════════════════════════════════════════════════════════════

        internal static LoadResult Load(string path)
        {
            if (string.IsNullOrWhiteSpace(path))
                return Make(path ?? "", "", LoadStatus.Skipped, "Empty path");

            path = path.Trim();
            string ext = Path.GetExtension(path).ToLowerInvariant();

            if (!File.Exists(path))
                return Make(path, ext, LoadStatus.NotFound, "File not found: " + path);

            // Post work to AutoCAD's application-context thread and block
            // until done.  ManualResetEventSlim avoids spinning.
            LoadResult? result = null;
            using var done = new ManualResetEventSlim(false);

            Application.DocumentManager.ExecuteInApplicationContext(
                delegate
                {
                    try
                    {
                        switch (ext)
                        {
                            case ".lsp":
                            case ".vlx":
                            case ".fas":
                                result = LoadLisp(path, ext);
                                break;
                            case ".dll":
                                result = LoadDll(path);
                                break;
                            default:
                                result = Make(path, ext, LoadStatus.Skipped,
                                             "Unsupported extension: " + ext);
                                break;
                        }
                    }
                    catch (SysEx ex)
                    {
                        result = Make(path, ext, LoadStatus.Failed,
                            "Unhandled error in application context: " + ex.Message);
                    }
                    finally
                    {
                        done.Set();
                    }
                },
                null);

            // 30 s timeout — graceful degradation if ACAD is waiting for modal input
            if (!done.Wait(TimeSpan.FromSeconds(30)))
            {
                LogManager.Warn("FileLoader",
                    $"Load timed out (30 s): {Path.GetFileName(path)}");
                return Make(path, ext, LoadStatus.Failed,
                    "Load timed out — AutoCAD may be waiting for user input.");
            }

            return result ?? Make(path, ext, LoadStatus.Failed, "No result returned.");
        }

        // ═════════════════════════════════════════════════════════════════════
        // LISP / VLX / FAS — runs on ACAD application-context thread
        // ═════════════════════════════════════════════════════════════════════

        private static LoadResult LoadLisp(string path, string ext)
        {
            var sw = Stopwatch.StartNew();
            try
            {
                Document? doc = Application.DocumentManager?.MdiActiveDocument;
                if (doc == null)
                    return Make(path, ext, LoadStatus.Failed,
                        "No active document — open a drawing first.", sw.Elapsed);

                // ── Strategy A: SendStringToExecute ───────────────────────────
                // Signature (AutoCAD 2010+):
                //   void SendStringToExecute(string commandString,
                //                            bool   activate,
                //                            bool   wrapUpInactiveDoc,
                //                            bool   echoCommand)
                // NOTE: named param is 'wrapUpInactiveDoc', NOT 'wrap'.
                // Use positional args to stay compatible across ACAD versions.
                try
                {
                    // LISP requires forward slashes in paths
                    string lispPath = path.Replace('\\', '/');
                    string lispExpr = "(load \"" + lispPath + "\")\n";

                    using (doc.LockDocument())
                    {
                        // positional: (commandString, activate, wrapUpInactiveDoc, echoCommand)
                        doc.SendStringToExecute(lispExpr, false, false, false);
                    }

                    sw.Stop();
                    LogManager.Info("FileLoader",
                        "[SendString] Loaded: " + Path.GetFileName(path));
                    return Make(path, ext, LoadStatus.OK, string.Empty, sw.Elapsed);
                }
                catch (SysEx ssEx)
                {
                    LogManager.Warn("FileLoader",
                        "SendStringToExecute failed for " + Path.GetFileName(path) +
                        ": " + ssEx.Message + " — trying acedInvoke.");
                }

                // ── Strategy B: P/Invoke acedInvoke ──────────────────────────
                if (_pinvokeAvailable)
                {
                    try
                    {
                        using (doc.LockDocument())
                        using (var rb = new ResultBuffer(
                            new TypedValue(RTLB),
                            new TypedValue(RTSTR, "load"),
                            new TypedValue(RTSTR, path),
                            new TypedValue(RTLE)))
                        {
                            AcedInvoke(rb.UnmanagedObject, out IntPtr _);
                        }
                        sw.Stop();
                        return Make(path, ext, LoadStatus.OK, string.Empty, sw.Elapsed);
                    }
                    catch (EntryPointNotFoundException epnf)
                    {
                        _pinvokeAvailable = false;
                        LogManager.Warn("FileLoader",
                            "acedInvoke entry not found: " + epnf.Message);
                    }
                    catch (DllNotFoundException dnf)
                    {
                        _pinvokeAvailable = false;
                        LogManager.Warn("FileLoader",
                            "accore.dll not found: " + dnf.Message);
                    }
                    catch (SysEx ex)
                    {
                        LogManager.Warn("FileLoader",
                            "acedInvoke threw: " + ex.Message + " — trying reflection.");
                    }
                }

                // ── Strategy C: Reflection ────────────────────────────────────
                MethodInfo? method = GetReflectMethod();
                if (method != null)
                {
                    try
                    {
                        using (doc.LockDocument())
                        using (var rb = new ResultBuffer(
                            new TypedValue(RTLB),
                            new TypedValue(RTSTR, "load"),
                            new TypedValue(RTSTR, path),
                            new TypedValue(RTLE)))
                        {
                            method.Invoke(null, new object?[] { rb, null });
                        }
                        sw.Stop();
                        return Make(path, ext, LoadStatus.OK, string.Empty, sw.Elapsed);
                    }
                    catch (SysEx ex)
                    {
                        sw.Stop();
                        return Make(path, ext, LoadStatus.Failed,
                            ex.InnerException?.Message ?? ex.Message, sw.Elapsed);
                    }
                }

                sw.Stop();
                return Make(path, ext, LoadStatus.Failed,
                    "All load strategies failed — run LISPLOADDIAG for details.", sw.Elapsed);
            }
            catch (SysEx ex)
            {
                sw.Stop();
                return Make(path, ext, LoadStatus.Failed, ex.Message, sw.Elapsed);
            }
        }

        // ═════════════════════════════════════════════════════════════════════
        // DLL — runs on ACAD application-context thread
        // ═════════════════════════════════════════════════════════════════════

        private static LoadResult LoadDll(string path)
        {
            var sw = Stopwatch.StartNew();
            try
            {
                System.Reflection.Assembly asm =
                    System.Reflection.Assembly.LoadFrom(path);
                ExtensionLoader.Load(path);
                sw.Stop();

                Version? verObj = asm.GetName().Version;
                string verNum = verObj != null
                    ? string.Format("{0}.{1}.{2:D3}", verObj.Major, verObj.Minor, verObj.Build)
                    : "?.?.???";

                string creationStamp;
                try   { creationStamp = File.GetCreationTime(path).ToString("dd.MM.yyyy_HH.mm.ss"); }
                catch { creationStamp = "??.??.????_??.??.??"; }

                // version stamp stored in ErrorMessage (re-used as info field for OK results)
                return Make(path, ".dll", LoadStatus.OK,
                    verNum + "_[" + creationStamp + "]", sw.Elapsed);
            }
            catch (SysEx ex)
            {
                sw.Stop();
                return Make(path, ".dll", LoadStatus.Failed, ex.Message, sw.Elapsed);
            }
        }

        // ═════════════════════════════════════════════════════════════════════
        // REFLECTION SCAN — cached after first successful search
        // ═════════════════════════════════════════════════════════════════════

        private static MethodInfo? GetReflectMethod()
        {
            if (_reflectSearched) return _reflectMethod;
            lock (_reflectLock)
            {
                if (_reflectSearched) return _reflectMethod;
                _reflectSearched = true;

                string[] targets = { "acmgd", "accoremgd", "acdbmgd", "acmgdui", "acapp" };

                foreach (System.Reflection.Assembly asm in
                         AppDomain.CurrentDomain.GetAssemblies())
                {
                    string asmName = asm.GetName().Name ?? "";
                    bool isTarget  = false;
                    foreach (string t in targets)
                        if (asmName.Equals(t, StringComparison.OrdinalIgnoreCase))
                        { isTarget = true; break; }
                    if (!isTarget) continue;

                    Type[] types;
                    try { types = asm.GetTypes(); } catch { continue; }

                    foreach (Type type in types)
                    {
                        MethodInfo[] methods;
                        try
                        {
                            methods = type.GetMethods(
                                BindingFlags.Public | BindingFlags.NonPublic |
                                BindingFlags.Static);
                        }
                        catch { continue; }

                        foreach (MethodInfo m in methods)
                        {
                            if (!m.Name.Equals("acedInvoke",
                                    StringComparison.OrdinalIgnoreCase)) continue;
                            ParameterInfo[] parms = m.GetParameters();
                            if (parms.Length < 1) continue;
                            if (parms[0].ParameterType != typeof(ResultBuffer) &&
                                parms[0].ParameterType != typeof(IntPtr)) continue;

                            LogManager.Info("FileLoader",
                                "acedInvoke found via reflection: " +
                                type.FullName + "." + m.Name);
                            _reflectMethod = m;
                            return m;
                        }
                    }
                }

                LogManager.Warn("FileLoader",
                    "acedInvoke not found via reflection — run LISPLOADDIAG.");
                return null;
            }
        }

        // ═════════════════════════════════════════════════════════════════════
        // FACTORY
        // ═════════════════════════════════════════════════════════════════════

        private static LoadResult Make(
            string path, string ext, LoadStatus status,
            string error, TimeSpan duration = default) =>
            new LoadResult(
                path,
                string.IsNullOrEmpty(ext) ? ".?" : ext,
                status, error, duration);
    }
}


// ===== FILE: VersionStamp.cs =====
using System;
using System.Linq;
using System.Reflection;

namespace LispLoaderExtra
{
    /// <summary>
    /// Prints the version banner whenever the plugin loads.
    ///
    /// Format:  v1.0.000 | built 12.06.2026 10:30:00
    ///
    /// Version   → AssemblyVersion set in &lt;Version&gt; in the .csproj
    /// Timestamp → AssemblyMetadata("BuildTimestamp", "dd.MM.yyyy_HH.mm.ss")
    ///             injected at compile time by the MSBuild SetBuildTimestamp target.
    ///             No generated .cs file required.
    /// </summary>
    internal static class VersionStamp
    {
        private const string Source = "LispLoader";

        internal static void Print()
        {
            Assembly asm = Assembly.GetExecutingAssembly();

            // ── Version ───────────────────────────────────────────────────────
            // Version.ToString(3) drops leading zeros from the build number:
            //   1.2.000 → "1.2.0" (wrong). Format manually to get "1.2.000".
            var v = asm.GetName().Version;
            string version = v != null
                ? v.Major + "." + v.Minor + "." + v.Build.ToString("D3")
                : "?.?.???";

            // ── Timestamp from AssemblyMetadata ───────────────────────────────
            // The .csproj target adds:
            //   [assembly: AssemblyMetadata("BuildTimestamp", "12.06.2026_10.30.00")]
            string raw = asm
                .GetCustomAttributes<AssemblyMetadataAttribute>()
                .FirstOrDefault(a => a.Key == "BuildTimestamp")
                ?.Value
                ?? "??.??.????_??.??.??";

            // raw = "12.06.2026_10.30.00"
            string[] halves = raw.Split('_');
            string date = halves.Length > 0 ? halves[0] : "??";                    // 12.06.2026
            string time = halves.Length > 1 ? halves[1].Replace('.', ':') : "??";  // 10:30:00

            string banner = $"v{version} | built {date} {time}";

            LogManager.Separator();
            LogManager.Info(Source, banner);
            LogManager.Separator();
        }
    }
}


// ===== FILE: LoaderWindow.cs =====
// No Autodesk.AutoCAD.Runtime using here — avoids Exception ambiguity.
// All ACAD calls go through FileLoader / LogManager / DiskScanner instead.
using System;
using System.Collections.Generic;
using System.Diagnostics;
using System.Drawing;
using System.IO;
using System.Linq;
using System.Windows.Forms;

namespace LispLoaderExtra
{
    /// <summary>
    /// Main loader window — type LISPLOADEXTRA in AutoCAD.
    ///
    /// v1.5 — compile-error fixes + new improvements
    /// ────────────────────────────────────────────────
    /// Fixes (from compiler errors reported on v1.4):
    ///   • 'Exception' ambiguity: no Autodesk.AutoCAD.Runtime using in this file;
    ///     all catches use System.Exception via the global alias.
    ///   • SendStringToExecute named-param 'wrap' → positional args in FileLoader.
    ///
    /// New in v1.5:
    ///   • "Load Selected" toolbar button + F3 shortcut
    ///   • Right-click context menu (Load / Reload / Open Folder / Copy Path /
    ///     Copy All Paths / Check / Uncheck)
    ///   • Progress bar in the status strip
    ///   • Column header tooltips
    ///   • DLL File cell shows version stamp in italic after load
    ///   • _loading guard prevents double-triggers
    ///   • FileSystemWatcher: auto-rescan when files change on disk
    ///   • Persist checked state to ss\checked.json between sessions
    ///   • "Open in Notepad++" right-click item (falls back to Notepad)
    ///   • Error-diff highlight: rows that changed FAIL→OK or OK→FAIL glow briefly
    ///
    /// Form behaviour:
    ///   FormBorderStyle.SizableToolWindow — small title bar, no taskbar entry
    ///   ProcessCmdKey swallows Escape (viewport-safe)
    ///   Modeless — stays open while AutoCAD is active
    ///   Live log panel (bottom pane) — real-time, colour-coded
    ///   Store Log / Clear / Auto-scroll
    /// </summary>
    internal sealed class LoaderWindow : Form
    {
        // ── Palette ───────────────────────────────────────────────────────────
        private static readonly Color BgDark    = Color.FromArgb(26,  26,  34);
        private static readonly Color BgPanel   = Color.FromArgb(36,  36,  48);
        private static readonly Color BgGrid    = Color.FromArgb(20,  20,  28);
        private static readonly Color BgSearch  = Color.FromArgb(44,  44,  58);
        private static readonly Color BgLog     = Color.FromArgb(16,  16,  22);
        private static readonly Color ColOk     = Color.FromArgb(80,  200, 100);
        private static readonly Color ColFail   = Color.FromArgb(220, 70,  70);
        private static readonly Color ColMiss   = Color.FromArgb(220, 155, 40);
        private static readonly Color ColText   = Color.FromArgb(210, 210, 222);
        private static readonly Color ColSub    = Color.FromArgb(120, 120, 138);
        private static readonly Color ColAccent = Color.FromArgb(80,  145, 215);
        private static readonly Color ColWarn   = Color.FromArgb(230, 160, 40);
        private static readonly Color ColError  = Color.FromArgb(220, 70,  70);
        private static readonly Color ColInfo   = Color.FromArgb(100, 200, 240);
        private static readonly Color ColLsp    = Color.FromArgb(100, 210, 120);
        private static readonly Color ColVlx    = Color.FromArgb(180, 130, 240);
        private static readonly Color ColFas    = Color.FromArgb(240, 185, 80);
        private static readonly Color ColDll    = Color.FromArgb(240, 205, 70);
        private static readonly Color ColC3D    = Color.FromArgb(110, 185, 240);
        private static readonly Color ColAcad   = Color.FromArgb(160, 230, 155);
        private static readonly Color ColFlash  = Color.FromArgb(255, 255, 100);  // diff-flash

        // ── Column indices ────────────────────────────────────────────────────
        private const int CI_Chk    = 0;
        private const int CI_Status = 1;
        private const int CI_Num    = 2;
        private const int CI_Cat    = 3;
        private const int CI_Menu   = 4;
        private const int CI_File   = 5;
        private const int CI_Ext    = 6;
        private const int CI_Ms     = 7;
        private const int CI_Path   = 8;

        // ── Checked-state persistence file ────────────────────────────────────
        private static readonly string CheckedFile =
            System.IO.Path.Combine(LogManager.LogFolder, "checked.json");

        // ── State ─────────────────────────────────────────────────────────────
        private List<ScannedFile> _allFiles  = new List<ScannedFile>();
        private List<ScannedFile> _visible   = new List<ScannedFile>();
        private bool _scanning  = false;
        private bool _loading   = false;

        // Tracks which files changed status in the last load (for flash)
        private readonly System.Collections.Generic.HashSet<string> _flashPaths
            = new System.Collections.Generic.HashSet<string>(
                StringComparer.OrdinalIgnoreCase);

        // FileSystemWatcher for auto-rescan
        private FileSystemWatcher? _watcher;
        private System.Windows.Forms.Timer? _rescanTimer;  // debounce

        // ── Controls — toolbar ────────────────────────────────────────────────
        private ComboBox  _cbCat      = null!;
        private ComboBox  _cbName     = null!;
        private TextBox   _txtSearch  = null!;
        private Button    _btnScan    = null!;
        private Button    _btnLoad    = null!;
        private Button    _btnReload  = null!;
        private Button    _btnLoadSel = null!;
        private Button    _btnAll     = null!;
        private Button    _btnNone    = null!;
        private Button    _btnReport  = null!;

        // ── Controls — main ───────────────────────────────────────────────────
        private DataGridView     _grid     = null!;
        private Label            _lblTitle = null!;
        private Label            _lblStatus = null!;
        private ProgressBar      _progress  = null!;
        private ToolTip          _tooltip   = null!;
        private ContextMenuStrip _ctxMenu   = null!;

        // ── Log panel ─────────────────────────────────────────────────────────
        private RichTextBox    _logBox        = null!;
        private Button         _btnStoreLog   = null!;
        private Button         _btnClearLog   = null!;
        private CheckBox       _chkAutoScroll = null!;
        private SplitContainer _split         = null!;

        // ── Constructor ───────────────────────────────────────────────────────

        internal LoaderWindow()
        {
            BuildLayout();

            LogManager.Subscribe(OnLogLine);

            // Seed log panel with prior session lines from ring-buffer
            foreach (string line in LogManager.GetRingSnapshot())
                AppendLogLine(line);

            LoadCheckedState();    // restore persisted checkbox ticks
            SetupWatcher();        // FileSystemWatcher for auto-rescan
            DoScan();
        }

        // ── Escape swallow ────────────────────────────────────────────────────

        protected override bool ProcessCmdKey(ref Message msg, Keys keyData)
        {
            if (keyData == Keys.Escape) return true;   // consumed — safe in viewport
            return base.ProcessCmdKey(ref msg, keyData);
        }

        // ── Cleanup ───────────────────────────────────────────────────────────

        protected override void OnFormClosed(FormClosedEventArgs e)
        {
            LogManager.Unsubscribe(OnLogLine);
            SaveCheckedState();
            TearDownWatcher();
            base.OnFormClosed(e);
        }

        // ═════════════════════════════════════════════════════════════════════
        // LAYOUT
        // ═════════════════════════════════════════════════════════════════════

        private void BuildLayout()
        {
            Text            = "LispLoaderExtra";
            Size            = new Size(1300, 840);
            MinimumSize     = new Size(920, 600);
            StartPosition   = FormStartPosition.CenterScreen;
            BackColor       = BgDark;
            ForeColor       = ColText;
            Font            = new Font("Segoe UI", 9f);
            FormBorderStyle = FormBorderStyle.SizableToolWindow;
            ShowInTaskbar   = false;
            KeyPreview      = true;
            KeyDown        += OnKeyDown;

            _tooltip = new ToolTip {
                AutoPopDelay = 10000,
                InitialDelay = 400,
                ReshowDelay  = 200,
                ShowAlways   = true,
            };

            BuildContextMenu();
            BuildTitleBar();
            BuildToolbar();
            BuildStatusBar();       // Dock.Bottom — must be added before Fill panel
            BuildSplitArea();
        }

        // ── Title bar ─────────────────────────────────────────────────────────

        private void BuildTitleBar()
        {
            var panel = new Panel { Dock = DockStyle.Top, Height = 42, BackColor = BgPanel };
            _lblTitle = new Label {
                Text      = "LispLoaderExtra",
                Font      = new Font("Segoe UI", 13f, FontStyle.Bold),
                ForeColor = ColAccent,
                BackColor = Color.Transparent,
                Dock      = DockStyle.Fill,
                TextAlign = ContentAlignment.MiddleLeft,
                Padding   = new Padding(12, 0, 0, 0),
            };
            panel.Controls.Add(_lblTitle);
            Controls.Add(panel);
        }

        // ── Toolbar ───────────────────────────────────────────────────────────

        private void BuildToolbar()
        {
            var tb = new Panel { Dock = DockStyle.Top, Height = 42, BackColor = BgPanel };
            int x  = 10;

            tb.Controls.Add(Lbl("Cat:", x, 12, 28));  x += 30;
            _cbCat = Combo(x, 7, 100);
            _cbCat.Items.AddRange(new object[] { "All", "AutoCAD", "Civil 3D" });
            _cbCat.SelectedIndex = 0;
            _cbCat.SelectedIndexChanged += OnCatChanged;
            tb.Controls.Add(_cbCat);  x += 108;

            tb.Controls.Add(Lbl("Name:", x, 12, 40));  x += 42;
            _cbName = Combo(x, 7, 190);
            _cbName.SelectedIndexChanged += OnNameChanged;
            tb.Controls.Add(_cbName);  x += 198;

            tb.Controls.Add(Lbl("🔍", x, 11, 20));  x += 22;
            _txtSearch = new TextBox {
                Location    = new Point(x, 8),
                Size        = new Size(150, 26),
                BackColor   = BgSearch,
                ForeColor   = ColText,
                Font        = new Font("Segoe UI", 9f),
                BorderStyle = BorderStyle.FixedSingle,
            };
            _txtSearch.TextChanged += (s, e) => ApplyFilters();
            tb.Controls.Add(_txtSearch);  x += 158;

            x += 8;
            _btnScan    = Btn("🔍 Scan",      ColAccent,                       80,  x, tb); x += 88;
            _btnLoad    = Btn("▶ Load",        Color.FromArgb(35, 120, 55),     78,  x, tb); x += 86;
            _btnReload  = Btn("🔄 Reload",     Color.FromArgb(35, 95,  125),    82,  x, tb); x += 90;
            _btnLoadSel = Btn("▶ Load Sel.",   Color.FromArgb(80, 100, 40),     90,  x, tb); x += 98;

            x += 6;
            _btnAll  = Btn("☑ All",  Color.FromArgb(55, 55, 70), 60, x, tb); x += 68;
            _btnNone = Btn("☐ None", Color.FromArgb(55, 55, 70), 60, x, tb);

            _btnReport = Btn("📊 Report", Color.FromArgb(75, 55, 110), 96, 0, tb);
            _btnReport.Anchor   = AnchorStyles.Top | AnchorStyles.Right;
            _btnReport.Location = new Point(tb.Width - 108, 6);
            tb.Resize += (s, e) => _btnReport.Location = new Point(tb.Width - 108, 6);
            tb.Controls.Add(_btnReport);

            _btnScan.Click    += (s, e) => DoScan();
            _btnLoad.Click    += (s, e) => DoLoad(LoadScope.Checked,  reload: false);
            _btnReload.Click  += (s, e) => DoLoad(LoadScope.Checked,  reload: true);
            _btnLoadSel.Click += (s, e) => DoLoad(LoadScope.Selected, reload: false);
            _btnAll.Click     += (s, e) => SetAllChecked(true);
            _btnNone.Click    += (s, e) => SetAllChecked(false);
            _btnReport.Click  += (s, e) => OpenReport();

            _tooltip.SetToolTip(_btnScan,    "Re-scan disk  (F5)");
            _tooltip.SetToolTip(_btnLoad,    "Load checked files — skip already-OK  (F2)");
            _tooltip.SetToolTip(_btnReload,  "Force-reload ALL checked files");
            _tooltip.SetToolTip(_btnLoadSel, "Load only highlighted grid row(s)  (F3)");
            _tooltip.SetToolTip(_btnAll,     "Check all visible rows  (Ctrl+A)");
            _tooltip.SetToolTip(_btnNone,    "Uncheck all visible rows");
            _tooltip.SetToolTip(_btnReport,  "Open full load-session report");

            Controls.Add(tb);
        }

        // ── Right-click context menu ──────────────────────────────────────────

        private void BuildContextMenu()
        {
            _ctxMenu = new ContextMenuStrip {
                BackColor  = Color.FromArgb(36, 36, 48),
                ForeColor  = ColText,
                Font       = new Font("Segoe UI", 9f),
                RenderMode = ToolStripRenderMode.System,
            };

            CtxItem("▶  Load Selected",          OnCtxLoad,       "Load selected rows on ACAD thread");
            CtxItem("🔄  Reload Selected",        OnCtxReload,     "Force-reload selected rows");
            _ctxMenu.Items.Add(new ToolStripSeparator());
            CtxItem("📂  Open Folder",            OnCtxOpenFolder, "Open file's folder in Explorer");
            CtxItem("📝  Open in Editor",         OnCtxOpenEditor, "Open in Notepad++ or Notepad");
            CtxItem("📋  Copy Path",              OnCtxCopyPath,   "Copy full path to clipboard");
            CtxItem("📋  Copy All Paths",         OnCtxCopyAllPaths,"Copy paths of all selected rows");
            _ctxMenu.Items.Add(new ToolStripSeparator());
            CtxItem("☑  Check Selected",          OnCtxCheck,      "Tick selected rows");
            CtxItem("☐  Uncheck Selected",        OnCtxUncheck,    "Untick selected rows");
        }

        private void CtxItem(string text, EventHandler h, string tip)
        {
            var item = new ToolStripMenuItem(text) {
                BackColor = Color.FromArgb(36, 36, 48),
                ForeColor = ColText,
            };
            item.Click += h;
            _ctxMenu.Items.Add(item);
        }

        // ── Status bar + progress ─────────────────────────────────────────────

        private void BuildStatusBar()
        {
            var bar = new Panel {
                Dock      = DockStyle.Bottom,
                Height    = 28,
                BackColor = Color.FromArgb(18, 18, 26),
            };

            _lblStatus = new Label {
                Dock      = DockStyle.Fill,
                ForeColor = ColSub,
                Font      = new Font("Consolas", 8f),
                TextAlign = ContentAlignment.MiddleLeft,
                Padding   = new Padding(10, 0, 0, 0),
            };

            _progress = new ProgressBar {
                Dock    = DockStyle.Right,
                Width   = 180,
                Minimum = 0,
                Maximum = 100,
                Value   = 0,
                Style   = ProgressBarStyle.Continuous,
                Visible = false,
            };

            bar.Controls.Add(_lblStatus);
            bar.Controls.Add(_progress);
            Controls.Add(bar);
        }

        // ── Split area: grid (top) / log (bottom) ─────────────────────────────

        private void BuildSplitArea()
        {
            _split = new SplitContainer {
                Dock             = DockStyle.Fill,
                Orientation      = Orientation.Horizontal,
                Panel1MinSize    = 180,
                Panel2MinSize    = 60,
                SplitterDistance = 510,
                BackColor        = BgDark,
                SplitterWidth    = 5,
            };
            BuildGrid();
            BuildLogPanel();
            Controls.Add(_split);
        }

        // ── Grid ──────────────────────────────────────────────────────────────

        private void BuildGrid()
        {
            _grid = new DataGridView {
                Dock              = DockStyle.Fill,
                BackgroundColor   = BgGrid,
                BorderStyle       = BorderStyle.None,
                RowHeadersVisible = false,
                AllowUserToAddRows    = false,
                AllowUserToDeleteRows = false,
                ReadOnly          = false,
                SelectionMode     = DataGridViewSelectionMode.FullRowSelect,
                MultiSelect       = true,
                AutoSizeRowsMode  = DataGridViewAutoSizeRowsMode.None,
                ColumnHeadersHeightSizeMode =
                    DataGridViewColumnHeadersHeightSizeMode.DisableResizing,
                ColumnHeadersHeight = 28,
                RowTemplate         = { Height = 22 },
                GridColor           = Color.FromArgb(40, 40, 54),
                DefaultCellStyle    = {
                    BackColor          = BgGrid,
                    ForeColor          = ColText,
                    SelectionBackColor = Color.FromArgb(48, 88, 138),
                    SelectionForeColor = Color.White,
                    Font               = new Font("Consolas", 8.5f),
                    Padding            = new Padding(3, 0, 3, 0),
                },
                ColumnHeadersDefaultCellStyle = {
                    BackColor          = Color.FromArgb(42, 42, 56),
                    ForeColor          = ColSub,
                    Font               = new Font("Segoe UI", 8.5f, FontStyle.Bold),
                    SelectionBackColor = Color.FromArgb(42, 42, 56),
                },
                EnableHeadersVisualStyles = false,
                ClipboardCopyMode         = DataGridViewClipboardCopyMode.EnableWithoutHeaderText,
                ContextMenuStrip          = _ctxMenu,
            };

            // Checkbox column
            _grid.Columns.Add(new DataGridViewCheckBoxColumn {
                HeaderText   = "☑",
                Width        = 30,
                ReadOnly     = false,
                Resizable    = DataGridViewTriState.False,
                AutoSizeMode = DataGridViewAutoSizeColumnMode.None,
            });

            AddCol("Status",    58,  false, "center", "Load result: OK / FAIL / MISSING / SKIP");
            AddCol("#",         46,  false, "center", "Row number after sort");
            AddCol("Cat",       68,  false, "center", "AutoCAD or Civil 3D");
            AddCol("Menu",      155, false, "left",   "Parent _menu folder name");
            AddCol("File",      230, true,  "left",   "File name — DLLs show version stamp after load");
            AddCol("Ext",       42,  false, "center", "File extension");
            AddCol("ms",        50,  false, "center", "Load time in milliseconds");
            AddCol("Full path", 380, true,  "left",   "Absolute path on disk");

            _grid.CellFormatting   += GridCellFormatting;
            _grid.CellValueChanged += GridCellValueChanged;
            _grid.CellDoubleClick  += GridCellDoubleClick;
            _grid.CellMouseMove    += GridCellMouseMove;

            // Commit checkbox immediately
            _grid.CurrentCellDirtyStateChanged += (s, e) => {
                if (_grid.IsCurrentCellDirty)
                    _grid.CommitEdit(DataGridViewDataErrorContexts.Commit);
            };

            // Header checkbox col → toggle all
            _grid.ColumnHeaderMouseClick += (s, e) => {
                if (e.ColumnIndex == CI_Chk)
                    SetAllChecked(_visible.Any(f => !f.Checked));
            };

            // Right-click — ensure clicked row is selected first
            _grid.CellMouseDown += (s, e) => {
                if (e.Button == MouseButtons.Right && e.RowIndex >= 0)
                    if (!_grid.Rows[e.RowIndex].Selected)
                    {
                        _grid.ClearSelection();
                        _grid.Rows[e.RowIndex].Selected = true;
                    }
            };

            _split.Panel1.Controls.Add(_grid);
        }

        // ── Log panel ─────────────────────────────────────────────────────────

        private void BuildLogPanel()
        {
            var logBar = new Panel { Dock = DockStyle.Top, Height = 32, BackColor = BgPanel };

            logBar.Controls.Add(new Label {
                Text      = "📋 Live Log",
                Location  = new Point(8, 7),
                Size      = new Size(82, 20),
                ForeColor = ColSub,
                Font      = new Font("Segoe UI", 8.5f, FontStyle.Bold),
                BackColor = Color.Transparent,
            });

            _btnStoreLog = LogBtn("💾 Store Log", Color.FromArgb(30, 60, 40),
                                  Color.FromArgb(55, 120, 75), 94);
            _btnStoreLog.Click += OnStoreLog;
            _tooltip.SetToolTip(_btnStoreLog,
                "Save live log to a timestamped file in the ss\\ folder");

            _btnClearLog = LogBtn("🗑 Clear", Color.FromArgb(50, 30, 30),
                                  Color.FromArgb(110, 55, 55), 192);
            _btnClearLog.Size   = new Size(68, 24);
            _btnClearLog.Click += (s, e) => _logBox.Clear();

            _chkAutoScroll = new CheckBox {
                Text      = "Auto-scroll",
                Location  = new Point(268, 7),
                Size      = new Size(92, 20),
                Checked   = true,
                ForeColor = ColSub,
                Font      = new Font("Segoe UI", 8f),
                BackColor = Color.Transparent,
            };

            logBar.Controls.AddRange(new Control[] {
                _btnStoreLog, _btnClearLog, _chkAutoScroll });

            _logBox = new RichTextBox {
                Dock        = DockStyle.Fill,
                BackColor   = BgLog,
                ForeColor   = ColText,
                Font        = new Font("Consolas", 8f),
                ReadOnly    = true,
                ScrollBars  = RichTextBoxScrollBars.Both,
                WordWrap    = false,
                BorderStyle = BorderStyle.None,
            };

            _split.Panel2.Controls.Add(_logBox);
            _split.Panel2.Controls.Add(logBar);
        }

        private Button LogBtn(string text, Color bg, Color border, int x)
        {
            var b = new Button {
                Text      = text,
                Location  = new Point(x, 4),
                Size      = new Size(90, 24),
                FlatStyle = FlatStyle.Flat,
                BackColor = bg,
                ForeColor = ColText,
                Font      = new Font("Segoe UI", 8f),
                Cursor    = Cursors.Hand,
                FlatAppearance = { BorderColor = border, BorderSize = 1 },
            };
            return b;
        }

        // ═════════════════════════════════════════════════════════════════════
        // FILE SYSTEM WATCHER — auto-rescan when disk changes
        // ═════════════════════════════════════════════════════════════════════

        private void SetupWatcher()
        {
            try
            {
                if (!Directory.Exists(DiskScanner.BaseFolder)) return;

                _watcher = new FileSystemWatcher(DiskScanner.BaseFolder) {
                    IncludeSubdirectories = true,
                    NotifyFilter = NotifyFilters.FileName | NotifyFilters.LastWrite |
                                   NotifyFilters.DirectoryName,
                    Filter  = "*.*",
                    EnableRaisingEvents = true,
                };

                // Debounce: wait 3 s of quiet after the last event before rescanning
                _rescanTimer = new System.Windows.Forms.Timer { Interval = 3000 };
                _rescanTimer.Tick += (s, e) => {
                    _rescanTimer.Stop();
                    if (IsHandleCreated && !IsDisposed)
                        Invoke((MethodInvoker)(() => {
                            LogManager.Info("LoaderWindow",
                                "FileSystemWatcher: disk change detected — rescanning.");
                            DoScan();
                        }));
                };

                FileSystemEventHandler kick = (s, e) => {
                    string ext = System.IO.Path.GetExtension(e.Name ?? "")
                                       .ToLowerInvariant();
                    if (ext == ".lsp" || ext == ".vlx" || ext == ".fas" || ext == ".dll")
                        if (IsHandleCreated && !IsDisposed)
                            Invoke((MethodInvoker)(() => _rescanTimer.Start()));
                };

                _watcher.Created += kick;
                _watcher.Deleted += kick;
                _watcher.Renamed += (s, e) => kick(s,
                    new FileSystemEventArgs(WatcherChangeTypes.Changed, e.FullPath, e.Name));

                LogManager.Info("LoaderWindow",
                    "FileSystemWatcher active on: " + DiskScanner.BaseFolder);
            }
            catch (System.Exception ex)
            {
                LogManager.Warn("LoaderWindow",
                    "FileSystemWatcher setup failed: " + ex.Message);
            }
        }

        private void TearDownWatcher()
        {
            try
            {
                _rescanTimer?.Stop();
                _rescanTimer?.Dispose();
                _watcher?.Dispose();
            }
            catch { }
        }

        // ═════════════════════════════════════════════════════════════════════
        // CHECKED-STATE PERSISTENCE
        // ═════════════════════════════════════════════════════════════════════
        // Simple line-delimited file: one full path per line = file is checked.
        // (Keeps net48 compat without pulling in System.Text.Json / Newtonsoft.)

        private void SaveCheckedState()
        {
            try
            {
                Directory.CreateDirectory(LogManager.LogFolder);
                var lines = _allFiles
                    .Where(f => f.Checked)
                    .Select(f => f.FullPath);
                File.WriteAllLines(CheckedFile, lines);
            }
            catch (System.Exception ex)
            {
                LogManager.Warn("LoaderWindow",
                    "Could not save checked state: " + ex.Message);
            }
        }

        private void LoadCheckedState()
        {
            try
            {
                if (!File.Exists(CheckedFile)) return;
                var checked_ = new System.Collections.Generic.HashSet<string>(
                    File.ReadAllLines(CheckedFile),
                    StringComparer.OrdinalIgnoreCase);

                foreach (var f in _allFiles)
                    f.Checked = checked_.Contains(f.FullPath);

                // Refresh grid checkboxes
                for (int i = 0; i < _visible.Count && i < _grid.Rows.Count; i++)
                    _grid.Rows[i].Cells[CI_Chk].Value = _visible[i].Checked;
            }
            catch (System.Exception ex)
            {
                LogManager.Warn("LoaderWindow",
                    "Could not restore checked state: " + ex.Message);
            }
        }

        // ═════════════════════════════════════════════════════════════════════
        // LIVE LOG
        // ═════════════════════════════════════════════════════════════════════

        private void OnLogLine(string line)
        {
            if (IsDisposed) return;
            if (InvokeRequired)
            {
                try { Invoke(new Action<string>(OnLogLine), line); }
                catch { }
                return;
            }
            AppendLogLine(line);
        }

        private void AppendLogLine(string line)
        {
            if (_logBox == null || _logBox.IsDisposed) return;

            Color c = ColText;
            if (line.IndexOf("[ERROR]", StringComparison.OrdinalIgnoreCase) >= 0) c = ColError;
            else if (line.IndexOf("[WARN ]", StringComparison.OrdinalIgnoreCase) >= 0) c = ColWarn;
            else if (line.IndexOf("[INFO ]", StringComparison.OrdinalIgnoreCase) >= 0) c = ColInfo;
            else if (line.StartsWith("───") || line.StartsWith("---"))              c = ColSub;

            int start = _logBox.TextLength;
            _logBox.AppendText(line + "\n");
            _logBox.Select(start, line.Length);
            _logBox.SelectionColor  = c;
            _logBox.SelectionLength = 0;

            if (_chkAutoScroll.Checked)
                _logBox.ScrollToCaret();
        }

        private void OnStoreLog(object? sender, EventArgs e)
        {
            try
            {
                string stamp   = DateTime.Now.ToString("yyyy-MM-dd_HH-mm-ss");
                string outFile = System.IO.Path.Combine(LogManager.LogFolder,
                                     "LispLoaderExtra_stored_" + stamp + ".log");
                Directory.CreateDirectory(LogManager.LogFolder);
                File.WriteAllText(outFile, _logBox.Text);
                LogManager.Info("LoaderWindow", "Log stored → " + outFile);
                MessageBox.Show("Log saved to:\n" + outFile, "LispLoaderExtra",
                    MessageBoxButtons.OK, MessageBoxIcon.Information);
            }
            catch (System.Exception ex)
            {
                MessageBox.Show("Failed to store log:\n" + ex.Message, "LispLoaderExtra",
                    MessageBoxButtons.OK, MessageBoxIcon.Warning);
            }
        }

        // ═════════════════════════════════════════════════════════════════════
        // CONTEXT MENU HANDLERS
        // ═════════════════════════════════════════════════════════════════════

        private void OnCtxLoad(object? s, EventArgs e)    => DoLoad(LoadScope.Selected, false);
        private void OnCtxReload(object? s, EventArgs e)  => DoLoad(LoadScope.Selected, true);
        private void OnCtxCheck(object? s, EventArgs e)   => SetSelectedChecked(true);
        private void OnCtxUncheck(object? s, EventArgs e) => SetSelectedChecked(false);

        private void OnCtxOpenFolder(object? s, EventArgs e)
        {
            var f = GetFirstSelectedFile();
            if (f == null) return;
            try
            {
                if (File.Exists(f.FullPath))
                    Process.Start("explorer.exe", "/select,\"" + f.FullPath + "\"");
                else
                {
                    string? dir = System.IO.Path.GetDirectoryName(f.FullPath);
                    if (dir != null && Directory.Exists(dir))
                        Process.Start("explorer.exe", dir);
                }
            }
            catch (System.Exception ex)
            {
                LogManager.Warn("LoaderWindow", "Explorer open failed: " + ex.Message);
            }
        }

        private void OnCtxOpenEditor(object? s, EventArgs e)
        {
            var f = GetFirstSelectedFile();
            if (f == null) return;
            if (!File.Exists(f.FullPath))
            {
                SetStatus("File not found: " + f.FullPath);
                return;
            }
            try
            {
                // Try Notepad++ first (most common on dev machines)
                string npp = System.IO.Path.Combine(
                    Environment.GetFolderPath(Environment.SpecialFolder.ProgramFiles),
                    "Notepad++", "notepad++.exe");
                if (!File.Exists(npp))
                    npp = System.IO.Path.Combine(
                        Environment.GetFolderPath(Environment.SpecialFolder.ProgramFilesX86),
                        "Notepad++", "notepad++.exe");

                string editor = File.Exists(npp) ? npp : "notepad.exe";
                Process.Start(editor, "\"" + f.FullPath + "\"");
            }
            catch (System.Exception ex)
            {
                LogManager.Warn("LoaderWindow", "Open in editor failed: " + ex.Message);
            }
        }

        private void OnCtxCopyPath(object? s, EventArgs e)
        {
            var f = GetFirstSelectedFile();
            if (f == null) return;
            try { Clipboard.SetText(f.FullPath); }
            catch { }
        }

        private void OnCtxCopyAllPaths(object? s, EventArgs e)
        {
            var paths = GetSelectedFiles().Select(f => f.FullPath);
            try { Clipboard.SetText(string.Join(Environment.NewLine, paths)); }
            catch { }
        }

        // ── Selection helpers ─────────────────────────────────────────────────

        private ScannedFile? GetFirstSelectedFile()
        {
            foreach (DataGridViewRow row in _grid.SelectedRows)
                if (row.Tag is ScannedFile f) return f;
            return null;
        }

        private List<ScannedFile> GetSelectedFiles()
        {
            var list = new List<ScannedFile>();
            var rows = _grid.SelectedRows.Cast<DataGridViewRow>()
                            .OrderBy(r => r.Index);
            foreach (var row in rows)
                if (row.Tag is ScannedFile f) list.Add(f);
            return list;
        }

        private void SetSelectedChecked(bool value)
        {
            foreach (DataGridViewRow row in _grid.SelectedRows)
            {
                row.Cells[CI_Chk].Value = value;
                if (row.Tag is ScannedFile f) f.Checked = value;
            }
            _grid.Refresh();
        }

        // ═════════════════════════════════════════════════════════════════════
        // SCAN
        // ═════════════════════════════════════════════════════════════════════

        private void DoScan()
        {
            if (_scanning) return;
            _scanning        = true;
            _btnScan.Text    = "Scanning…";
            _btnScan.Enabled = false;
            SetStatus("Scanning disk…");
            Application.DoEvents();

            _grid.Rows.Clear();
            _allFiles.Clear();

            try
            {
                _allFiles = DiskScanner.Scan();
                LoadCheckedState();        // restore ticks after rescan
                RefreshNameDropdown();
                UpdateTitleAndStatus();
            }
            catch (System.Exception ex)
            {
                LogManager.Error("LoaderWindow", "Scan failed: " + ex.Message);
                SetStatus("Scan failed: " + ex.Message);
            }
            finally
            {
                _scanning        = false;
                _btnScan.Text    = "🔍 Scan";
                _btnScan.Enabled = true;
            }
        }

        // ═════════════════════════════════════════════════════════════════════
        // DROPDOWNS / FILTER
        // ═════════════════════════════════════════════════════════════════════

        private void OnCatChanged(object sender, EventArgs e)  => RefreshNameDropdown();
        private void OnNameChanged(object sender, EventArgs e) => ApplyFilters();

        private void RefreshNameDropdown()
        {
            string cat = _cbCat.SelectedItem?.ToString() ?? "All";
            _cbName.SelectedIndexChanged -= OnNameChanged;
            _cbName.Items.Clear();
            _cbName.Items.Add("All");
            foreach (var n in DiskScanner.GetMenuNames(cat, _allFiles))
                _cbName.Items.Add(n);
            _cbName.SelectedIndex = 0;
            _cbName.SelectedIndexChanged += OnNameChanged;
            ApplyFilters();
        }

        private void ApplyFilters()
        {
            string cat    = _cbCat.SelectedItem?.ToString()  ?? "All";
            string name   = _cbName.SelectedItem?.ToString() ?? "All";
            string search = _txtSearch.Text.Trim();

            _visible = _allFiles
                .Where(f => cat  == "All" ||
                            string.Equals(f.Category, cat,  StringComparison.OrdinalIgnoreCase))
                .Where(f => name == "All" ||
                            string.Equals(f.MenuName, name, StringComparison.OrdinalIgnoreCase))
                .Where(f => search == "" ||
                            f.FileName.IndexOf(search, StringComparison.OrdinalIgnoreCase) >= 0 ||
                            f.MenuName.IndexOf(search, StringComparison.OrdinalIgnoreCase) >= 0)
                .ToList();

            PopulateGrid();
            UpdateTitleAndStatus();
        }

        // ═════════════════════════════════════════════════════════════════════
        // GRID POPULATION
        // ═════════════════════════════════════════════════════════════════════

        private void PopulateGrid()
        {
            _grid.SuspendLayout();
            _grid.Rows.Clear();

            foreach (var f in _visible)
            {
                int i   = _grid.Rows.Add();
                var row = _grid.Rows[i];
                row.Tag = f;

                row.Cells[CI_Chk   ].Value = f.Checked;
                row.Cells[CI_Status].Value = StatusLabel(f);
                row.Cells[CI_Num   ].Value = f.RowIndex.ToString();
                row.Cells[CI_Cat   ].Value = f.Category;
                row.Cells[CI_Menu  ].Value = f.MenuName;
                row.Cells[CI_File  ].Value = FileDisplayName(f);
                row.Cells[CI_Ext   ].Value = f.TypeLabel;
                row.Cells[CI_Ms    ].Value = f.LastResult != null
                    ? f.LastResult.Duration.TotalMilliseconds.ToString("0") : "";
                row.Cells[CI_Path  ].Value = f.FullPath;
            }

            _grid.ResumeLayout();
        }

        private void RefreshRow(int gridRow, ScannedFile f)
        {
            if (gridRow < 0 || gridRow >= _grid.Rows.Count) return;
            var row = _grid.Rows[gridRow];
            row.Cells[CI_Status].Value = StatusLabel(f);
            row.Cells[CI_File  ].Value = FileDisplayName(f);
            row.Cells[CI_Ms    ].Value = f.LastResult != null
                ? f.LastResult.Duration.TotalMilliseconds.ToString("0") : "";
        }

        private static string FileDisplayName(ScannedFile f)
        {
            if (f.Extension == ".dll" &&
                f.LastResult?.Status == LoadStatus.OK &&
                !string.IsNullOrEmpty(f.LastResult.ErrorMessage))
                return f.FileName + "  ·  " + f.LastResult.ErrorMessage;
            return f.FileName;
        }

        private static string StatusLabel(ScannedFile f) =>
            f.LastResult == null ? "" :
            f.LastResult.Status == LoadStatus.OK       ? "OK"      :
            f.LastResult.Status == LoadStatus.Failed   ? "FAIL"    :
            f.LastResult.Status == LoadStatus.NotFound ? "MISSING" :
            f.LastResult.Status == LoadStatus.Skipped  ? "SKIP"    : "";

        // ═════════════════════════════════════════════════════════════════════
        // LOAD / RELOAD
        // ═════════════════════════════════════════════════════════════════════

        private enum LoadScope { Checked, Selected }

        private void DoLoad(LoadScope scope, bool reload)
        {
            if (_loading) { SetStatus("Load already in progress."); return; }

            // ── Build work list ───────────────────────────────────────────────
            var toLoad = new List<(ScannedFile file, int row)>();

            if (scope == LoadScope.Selected)
            {
                var rows = _grid.SelectedRows.Cast<DataGridViewRow>()
                                .OrderBy(r => r.Index);
                foreach (var row in rows)
                {
                    if (!(row.Tag is ScannedFile f)) continue;
                    int vi = _visible.IndexOf(f);
                    if (vi >= 0) toLoad.Add((f, vi));
                }
            }
            else
            {
                for (int i = 0; i < _visible.Count; i++)
                {
                    var f    = _visible[i];
                    bool chk = _grid.Rows[i].Cells[CI_Chk].Value as bool? ?? false;
                    if (!chk) continue;
                    if (!reload && f.LastResult?.Status == LoadStatus.OK) continue;
                    toLoad.Add((f, i));
                }
            }

            if (toLoad.Count == 0)
            {
                SetStatus(scope == LoadScope.Selected
                    ? "No rows selected."
                    : reload ? "Nothing checked to reload."
                             : "All checked files already OK — use 🔄 Reload to force.");
                return;
            }

            // ── Lock UI ───────────────────────────────────────────────────────
            _loading            = true;
            _btnLoad.Enabled    = false;
            _btnReload.Enabled  = false;
            _btnLoadSel.Enabled = false;
            _btnScan.Enabled    = false;
            _progress.Maximum   = toLoad.Count;
            _progress.Value     = 0;
            _progress.Visible   = true;
            _flashPaths.Clear();

            try
            {
                LoadSession.Begin();
                int ok = 0, fail = 0, miss = 0;

                for (int idx = 0; idx < toLoad.Count; idx++)
                {
                    var (file, gridRow) = toLoad[idx];
                    LoadStatus prevStatus = file.LastResult?.Status ?? LoadStatus.Skipped;

                    SetStatus("Loading " + (idx + 1) + " / " + toLoad.Count +
                              ":  " + file.FileName);
                    _progress.Value = idx + 1;
                    Application.DoEvents();

                    // FileLoader.Load marshals to ACAD thread internally
                    LoadResult result = FileLoader.Load(file.FullPath);
                    file.LastResult   = result;
                    LoadSession.Add(result);
                    RefreshRow(gridRow, file);
                    _grid.InvalidateRow(gridRow);
                    Application.DoEvents();

                    // Track status changes for flash highlighting
                    if (result.Status != prevStatus)
                        _flashPaths.Add(file.FullPath);

                    switch (result.Status)
                    {
                        case LoadStatus.OK:       ok++;   break;
                        case LoadStatus.Failed:   fail++; break;
                        case LoadStatus.NotFound: miss++; break;
                    }
                }

                _grid.Refresh();
                FlashChangedRows();     // brief highlight for rows that changed status

                string summary = "Done — ✓ OK: " + ok;
                if (fail > 0) summary += "   ✗ FAILED: " + fail;
                if (miss > 0) summary += "   ⚠ NOT FOUND: " + miss;
                summary += "   (" + LoadSession.TotalDuration.TotalSeconds.ToString("0.0") + "s)";
                if (fail > 0 || miss > 0) summary += "   — 📊 Report for details";
                SetStatus(summary);
                UpdateTitleAndStatus();

                LogManager.Separator();
                LogManager.Info("LoaderWindow", LoadSession.SummaryLine);
                LogManager.Separator();
            }
            finally
            {
                _loading            = false;
                _btnLoad.Enabled    = true;
                _btnReload.Enabled  = true;
                _btnLoadSel.Enabled = true;
                _btnScan.Enabled    = true;
                _progress.Visible   = false;
            }
        }

        // ── Status-change flash ───────────────────────────────────────────────
        // Briefly highlights rows whose status changed so the user can spot
        // what actually changed without scanning the whole grid.

        private void FlashChangedRows()
        {
            if (_flashPaths.Count == 0) return;

            // Paint flash colour for 600 ms then restore normal formatting
            var flashTimer = new System.Windows.Forms.Timer { Interval = 600 };
            flashTimer.Tick += (s, e) => {
                flashTimer.Stop();
                flashTimer.Dispose();
                _flashPaths.Clear();
                _grid.Refresh();
            };

            // The CellFormatting handler already checks _flashPaths
            _grid.Refresh();
            flashTimer.Start();
        }

        // ═════════════════════════════════════════════════════════════════════
        // GRID EVENTS
        // ═════════════════════════════════════════════════════════════════════

        private void GridCellValueChanged(object sender, DataGridViewCellEventArgs e)
        {
            if (e.ColumnIndex != CI_Chk || e.RowIndex < 0) return;
            if (_grid.Rows[e.RowIndex].Tag is ScannedFile f)
                f.Checked = _grid.Rows[e.RowIndex].Cells[CI_Chk].Value as bool? ?? false;
        }

        private void GridCellDoubleClick(object sender, DataGridViewCellEventArgs e)
        {
            if (e.RowIndex < 0 || e.ColumnIndex == CI_Chk) return;
            if (!(_grid.Rows[e.RowIndex].Tag is ScannedFile f)) return;
            try
            {
                if (File.Exists(f.FullPath))
                    Process.Start("explorer.exe", "/select,\"" + f.FullPath + "\"");
                else
                {
                    string? dir = System.IO.Path.GetDirectoryName(f.FullPath);
                    if (dir != null && Directory.Exists(dir))
                        Process.Start("explorer.exe", dir);
                }
            }
            catch (System.Exception ex)
            {
                LogManager.Warn("LoaderWindow", "Explorer open failed: " + ex.Message);
            }
        }

        private string _lastTooltipPath = "";

        private void GridCellMouseMove(object sender, DataGridViewCellMouseEventArgs e)
        {
            if (e.RowIndex < 0) return;
            if (!(_grid.Rows[e.RowIndex].Tag is ScannedFile f)) return;
            if (f.FullPath == _lastTooltipPath) return;
            _lastTooltipPath = f.FullPath;

            string tip = f.FullPath;
            if (f.LastResult?.Status == LoadStatus.Failed)
                tip += "\n\nError: " + f.LastResult.ErrorMessage;
            else if (f.LastResult?.Status == LoadStatus.OK && f.Extension == ".dll")
                tip += "\n\nLoaded OK  (" +
                       f.LastResult.Duration.TotalMilliseconds.ToString("0") + " ms)" +
                       "\nVersion: " + f.LastResult.ErrorMessage;
            else if (f.LastResult?.Status == LoadStatus.OK)
                tip += "\n\nLoaded OK  (" +
                       f.LastResult.Duration.TotalMilliseconds.ToString("0") + " ms)";

            tip += "\n\nRight-click for options  •  Double-click to open folder";
            _tooltip.SetToolTip(_grid, tip);
        }

        private void GridCellFormatting(object sender, DataGridViewCellFormattingEventArgs e)
        {
            if (e.RowIndex < 0 || e.RowIndex >= _grid.Rows.Count) return;
            if (!(_grid.Rows[e.RowIndex].Tag is ScannedFile f)) return;

            // Flash rows that changed status in the last load
            if (_flashPaths.Contains(f.FullPath))
            {
                e.CellStyle.BackColor = Color.FromArgb(60, 55, 20);
                e.CellStyle.ForeColor = ColFlash;
                return;
            }

            // Status column
            if (e.ColumnIndex == CI_Status && f.LastResult != null)
            {
                e.CellStyle.ForeColor = f.LastResult.Status == LoadStatus.OK   ? ColOk  :
                                        f.LastResult.Status == LoadStatus.Failed ? ColFail :
                                        f.LastResult.Status == LoadStatus.NotFound ? ColMiss :
                                        ColSub;
                e.CellStyle.Font = new Font("Consolas", 8f, FontStyle.Bold);
            }

            // Extension / file colour
            if (e.ColumnIndex == CI_Ext || e.ColumnIndex == CI_File)
            {
                e.CellStyle.ForeColor = f.Extension == ".lsp" ? ColLsp :
                                        f.Extension == ".vlx" ? ColVlx :
                                        f.Extension == ".fas" ? ColFas :
                                        f.Extension == ".dll" ? ColDll : ColText;

                // DLL with version: italic
                if (e.ColumnIndex == CI_File && f.Extension == ".dll" &&
                    f.LastResult?.Status == LoadStatus.OK)
                    e.CellStyle.Font = new Font("Consolas", 8.5f, FontStyle.Italic);
            }

            // Category colour
            if (e.ColumnIndex == CI_Cat)
                e.CellStyle.ForeColor = f.Category == "Civil 3D" ? ColC3D : ColAcad;

            // Dim missing rows
            if (f.LastResult?.Status == LoadStatus.NotFound)
                e.CellStyle.ForeColor = Color.FromArgb(
                    (int)(e.CellStyle.ForeColor.R * 0.5),
                    (int)(e.CellStyle.ForeColor.G * 0.5),
                    (int)(e.CellStyle.ForeColor.B * 0.5));
        }

        // ═════════════════════════════════════════════════════════════════════
        // KEYBOARD SHORTCUTS
        // ═════════════════════════════════════════════════════════════════════

        private void OnKeyDown(object sender, KeyEventArgs e)
        {
            switch (e.KeyCode)
            {
                case Keys.F5:
                    DoScan();
                    e.Handled = true;
                    break;
                case Keys.F2:
                    DoLoad(LoadScope.Checked, false);
                    e.Handled = true;
                    break;
                case Keys.F3:
                    DoLoad(LoadScope.Selected, false);
                    e.Handled = true;
                    break;
                case Keys.A when e.Control:
                    SetAllChecked(true);
                    e.Handled = true;
                    break;
            }
        }

        // ═════════════════════════════════════════════════════════════════════
        // HELPERS
        // ═════════════════════════════════════════════════════════════════════

        private void SetAllChecked(bool value)
        {
            _grid.SuspendLayout();
            foreach (DataGridViewRow row in _grid.Rows)
            {
                row.Cells[CI_Chk].Value = value;
                if (row.Tag is ScannedFile f) f.Checked = value;
            }
            _grid.ResumeLayout();
            _grid.Refresh();
        }

        private void OpenReport()
        {
            using var win = new ReportWindow();
            win.ShowDialog(this);
        }

        private void SetStatus(string text) => _lblStatus.Text = text;

        private void UpdateTitleAndStatus()
        {
            int total  = _visible.Count;
            int lsp    = _visible.Count(f => f.Extension == ".lsp");
            int vlx    = _visible.Count(f => f.Extension == ".vlx");
            int fas    = _visible.Count(f => f.Extension == ".fas");
            int dll    = _visible.Count(f => f.Extension == ".dll");
            int loaded = _visible.Count(f => f.LastResult?.Status == LoadStatus.OK);
            int failed = _visible.Count(f => f.LastResult?.Status == LoadStatus.Failed);

            _lblTitle.Text =
                "LispLoaderExtra   " + _allFiles.Count + " files discovered" +
                (_allFiles.Count != total ? "  │  " + total + " showing" : "");

            string s = "Showing " + total +
                       "  │  LSP: " + lsp + "  VLX: " + vlx +
                       "  FAS: " + fas + "  DLL: " + dll;
            if (loaded > 0 || failed > 0)
                s += "  │  ✓ " + loaded + "  ✗ " + failed;
            SetStatus(s);
        }

        // ── Widget factories ──────────────────────────────────────────────────

        private void AddCol(string hdr, int w, bool fill, string align, string tip = "")
        {
            _grid.Columns.Add(new DataGridViewTextBoxColumn {
                HeaderText   = hdr,
                Width        = w,
                ReadOnly     = true,
                AutoSizeMode = fill
                    ? DataGridViewAutoSizeColumnMode.Fill
                    : DataGridViewAutoSizeColumnMode.None,
                SortMode     = DataGridViewColumnSortMode.Automatic,
                Resizable    = DataGridViewTriState.True,
                ToolTipText  = tip,
                DefaultCellStyle = {
                    Alignment = align == "center"
                        ? DataGridViewContentAlignment.MiddleCenter
                        : DataGridViewContentAlignment.MiddleLeft,
                },
            });
        }

        private static Label Lbl(string text, int x, int y, int w) =>
            new Label {
                Text      = text,
                Location  = new Point(x, y),
                Size      = new Size(w, 20),
                ForeColor = ColSub,
                BackColor = Color.Transparent,
                Font      = new Font("Segoe UI", 9f),
                TextAlign = ContentAlignment.MiddleLeft,
            };

        private static ComboBox Combo(int x, int y, int w) =>
            new ComboBox {
                Location      = new Point(x, y),
                Size          = new Size(w, 26),
                DropDownStyle = ComboBoxStyle.DropDownList,
                BackColor     = Color.FromArgb(48, 48, 62),
                ForeColor     = ColText,
                Font          = new Font("Segoe UI", 9f),
                FlatStyle     = FlatStyle.Flat,
            };

        private static Button Btn(string text, Color border, int w, int x, Panel tb)
        {
            var b = new Button {
                Text      = text,
                Location  = new Point(x, 6),
                Size      = new Size(w, 30),
                FlatStyle = FlatStyle.Flat,
                BackColor = Color.FromArgb(
                    Math.Max(0, border.R / 3),
                    Math.Max(0, border.G / 3),
                    Math.Max(0, border.B / 3)),
                ForeColor = Color.FromArgb(220, 220, 232),
                Font      = new Font("Segoe UI", 8.5f),
                Cursor    = Cursors.Hand,
                FlatAppearance = { BorderColor = border, BorderSize = 1 },
            };
            if (x > 0) tb.Controls.Add(b);
            return b;
        }
    }
}


// ===== FILE: ReportWindow.cs =====
using System;
using System.Collections.Generic;
using System.Diagnostics;
using System.Drawing;
using System.IO;
using System.Linq;
using System.Windows.Forms;

namespace LispLoaderExtra
{
    /// <summary>
    /// WinForms report window — shows the full load session results.
    /// Open anytime by typing LISPLOADREPORT in AutoCAD.
    /// </summary>
    internal sealed class ReportWindow : Form
    {
        // ── Colours ───────────────────────────────────────────────────────────
        private static readonly Color BgDark    = Color.FromArgb(30,  30,  30);
        private static readonly Color BgPanel   = Color.FromArgb(40,  40,  40);
        private static readonly Color BgGrid    = Color.FromArgb(25,  25,  25);
        private static readonly Color ColOk     = Color.FromArgb(60,  180, 90);
        private static readonly Color ColFail   = Color.FromArgb(220, 60,  60);
        private static readonly Color ColMiss   = Color.FromArgb(220, 150, 40);
        private static readonly Color ColSkip   = Color.FromArgb(120, 120, 120);
        private static readonly Color ColText   = Color.FromArgb(220, 220, 220);
        private static readonly Color ColSub    = Color.FromArgb(150, 150, 150);
        private static readonly Color ColAccent = Color.FromArgb(80,  140, 210);

        // ── Controls ──────────────────────────────────────────────────────────
        private DataGridView _grid       = null!;
        private Label        _lblSummary = null!;
        private Label        _lblStats   = null!;
        private TextBox      _txtError   = null!;
        private Button       _btnAll     = null!;
        private Button       _btnErrors  = null!;
        private Button       _btnOk      = null!;
        private Button       _btnCopy    = null!;
        private Button       _btnLog     = null!;
        private Button       _btnReload  = null!;
        private Label        _lblVersion = null!;

        private List<LoadResult> _current = new List<LoadResult>();

        // ── Constructor ───────────────────────────────────────────────────────

        internal ReportWindow()
        {
            BuildLayout();
            Refresh_All();
        }

        // ── Layout ────────────────────────────────────────────────────────────

        private void BuildLayout()
        {
            Text            = "LispLoaderExtra — Load Report";
            Size            = new Size(1050, 680);
            MinimumSize     = new Size(800, 500);
            StartPosition   = FormStartPosition.CenterScreen;
            BackColor       = BgDark;
            ForeColor       = ColText;
            Font            = new Font("Segoe UI", 9f);
            FormBorderStyle = FormBorderStyle.Sizable;

            // ── Top bar ───────────────────────────────────────────────────────
            var top = new Panel {
                Dock = DockStyle.Top, Height = 90, BackColor = BgPanel,
                Padding = new Padding(12, 8, 12, 8)
            };

            _lblSummary = MakeLabel("", 13f, bold: true);
            _lblSummary.Location = new Point(12, 10);
            _lblSummary.Size     = new Size(700, 24);
            _lblSummary.ForeColor = ColAccent;

            _lblStats = MakeLabel("", 9f);
            _lblStats.Location = new Point(12, 36);
            _lblStats.Size     = new Size(900, 18);
            _lblStats.ForeColor = ColSub;

            _lblVersion = MakeLabel("", 8.5f);
            _lblVersion.Location  = new Point(12, 56);
            _lblVersion.Size      = new Size(900, 16);
            _lblVersion.ForeColor = ColSub;

            top.Controls.AddRange(new Control[] { _lblSummary, _lblStats, _lblVersion });

            // ── Toolbar ───────────────────────────────────────────────────────
            var toolbar = new Panel {
                Dock = DockStyle.Top, Height = 38, BackColor = BgPanel,
                Padding = new Padding(8, 4, 8, 4)
            };

            _btnAll    = MakeFilterBtn("All",     0);
            _btnErrors = MakeFilterBtn("Errors",  1);
            _btnOk     = MakeFilterBtn("OK only", 2);

            _btnCopy = MakeActionBtn("📋 Copy Report", ColAccent);
            _btnLog  = MakeActionBtn("📄 Open Log",    Color.FromArgb(70,70,90));
            _btnReload = MakeActionBtn("🔄 Reload",    Color.FromArgb(60,90,60));

            _btnCopy.Click   += (s,e) => CopyReport();
            _btnLog.Click    += (s,e) => OpenLog();
            _btnReload.Click += (s,e) => Refresh_All();
            _btnAll.Click    += (s,e) => ApplyFilter(null);
            _btnErrors.Click += (s,e) => ApplyFilter(LoadStatus.Failed);
            _btnOk.Click     += (s,e) => ApplyFilter(LoadStatus.OK);

            // Layout buttons left-to-right
            int x = 8;
            foreach (var b in new[] { _btnAll, _btnErrors, _btnOk })
            { b.Location = new Point(x, 5); x += b.Width + 4; }

            x += 20;
            foreach (var b in new[] { _btnCopy, _btnLog, _btnReload })
            { b.Location = new Point(x, 5); x += b.Width + 4; }

            toolbar.Controls.AddRange(new Control[] {
                _btnAll, _btnErrors, _btnOk, _btnCopy, _btnLog, _btnReload });

            // ── Grid ──────────────────────────────────────────────────────────
            _grid = new DataGridView {
                Dock              = DockStyle.Fill,
                BackgroundColor   = BgGrid,
                BorderStyle       = BorderStyle.None,
                RowHeadersVisible = false,
                AllowUserToAddRows    = false,
                AllowUserToDeleteRows = false,
                ReadOnly          = true,
                SelectionMode     = DataGridViewSelectionMode.FullRowSelect,
                MultiSelect       = false,
                AutoSizeRowsMode  = DataGridViewAutoSizeRowsMode.None,
                ColumnHeadersHeightSizeMode = DataGridViewColumnHeadersHeightSizeMode.DisableResizing,
                ColumnHeadersHeight = 28,
                RowTemplate         = { Height = 22 },
                GridColor           = Color.FromArgb(50, 50, 50),
                DefaultCellStyle    = {
                    BackColor    = BgGrid,
                    ForeColor    = ColText,
                    SelectionBackColor = Color.FromArgb(55, 95, 145),
                    SelectionForeColor = Color.White,
                    Font         = new Font("Consolas", 8.5f),
                    Padding      = new Padding(3, 0, 3, 0),
                },
                ColumnHeadersDefaultCellStyle = {
                    BackColor = Color.FromArgb(50, 50, 60),
                    ForeColor = ColSub,
                    Font      = new Font("Segoe UI", 8.5f, FontStyle.Bold),
                    SelectionBackColor = Color.FromArgb(50,50,60),
                },
                EnableHeadersVisualStyles = false,
            };

            AddCol("Status",    60,  false);
            AddCol("Type",      42,  false);
            AddCol("File name", 220, true);
            AddCol("ms",        48,  false);
            AddCol("Full path", 480, true);

            _grid.SelectionChanged += GridSelectionChanged;
            _grid.CellFormatting   += GridCellFormatting;

            // ── Error detail panel ────────────────────────────────────────────
            var errPanel = new Panel {
                Dock      = DockStyle.Bottom,
                Height    = 90,
                BackColor = Color.FromArgb(35, 20, 20),
                Padding   = new Padding(8, 4, 8, 4),
            };

            var errLabel = MakeLabel("Error detail:", 8.5f, bold: true);
            errLabel.ForeColor = ColFail;
            errLabel.Location  = new Point(8, 4);
            errLabel.Size      = new Size(100, 16);

            _txtError = new TextBox {
                Multiline   = true,
                ReadOnly    = true,
                ScrollBars  = ScrollBars.Vertical,
                BackColor   = Color.FromArgb(35, 20, 20),
                ForeColor   = Color.FromArgb(240, 100, 100),
                Font        = new Font("Consolas", 8.5f),
                BorderStyle = BorderStyle.None,
                Location    = new Point(8, 22),
                Size        = new Size(1020, 60),
                Anchor      = AnchorStyles.Left | AnchorStyles.Right | AnchorStyles.Top | AnchorStyles.Bottom,
                Text        = "(select a row to see error detail)",
            };
            errPanel.Controls.AddRange(new Control[] { errLabel, _txtError });

            // ── Splitter + content area ────────────────────────────────────────
            var split = new SplitContainer {
                Dock        = DockStyle.Fill,
                Orientation = Orientation.Horizontal,
                Panel1MinSize = 200,
                Panel2MinSize = 60,
                SplitterDistance = 430,
                BackColor   = BgDark,
            };
            split.Panel1.Controls.Add(_grid);
            split.Panel2.Controls.Add(_txtError);
            split.Panel2.Controls.Add(errLabel);

            Controls.Add(split);
            Controls.Add(toolbar);
            Controls.Add(top);
        }

        // ── Data ─────────────────────────────────────────────────────────────

        private void Refresh_All()
        {
            _current = LoadSession.Results.ToList();
            PopulateGrid(_current);
            UpdateSummary();
        }

        private void ApplyFilter(LoadStatus? status)
        {
            _current = status.HasValue
                ? LoadSession.Results.Where(r => r.Status == status.Value).ToList()
                : LoadSession.Results.ToList();
            PopulateGrid(_current);

            // Highlight active filter button
            foreach (var b in new[] { _btnAll, _btnErrors, _btnOk })
                b.FlatAppearance.BorderColor = BgPanel;

            var active = status switch {
                LoadStatus.Failed => _btnErrors,
                LoadStatus.OK     => _btnOk,
                _                 => _btnAll,
            };
            active.FlatAppearance.BorderColor = ColAccent;
        }

        private void PopulateGrid(List<LoadResult> items)
        {
            _grid.Rows.Clear();
            foreach (var r in items)
            {
                int i = _grid.Rows.Add(
                    StatusLabel(r.Status),
                    r.TypeLabel,
                    r.FileName,
                    r.Duration.TotalMilliseconds.ToString("0"),
                    r.Path);
                _grid.Rows[i].Tag = r;
            }
        }

        private void UpdateSummary()
        {
            int total = LoadSession.TotalCount;
            int ok    = LoadSession.OkCount;
            int fail  = LoadSession.FailCount;
            int miss  = LoadSession.NotFoundCount;

            _lblSummary.Text =
                $"Loaded {ok} / {total} files   " +
                (fail > 0 ? $"⚠  {fail} error(s)   " : "") +
                (miss > 0 ? $"⚠  {miss} not found   " : "");

            _lblStats.Text =
                $"LSP: {LoadSession.CountByType(".lsp")}   " +
                $"VLX: {LoadSession.CountByType(".vlx")}   " +
                $"FAS: {LoadSession.CountByType(".fas")}   " +
                $"DLL: {LoadSession.CountByType(".dll")}   " +
                $"│  Total time: {LoadSession.TotalDuration.TotalSeconds:0.00}s   " +
                $"│  Log: {LogManager.LogFolder}";

            _lblVersion.Text =
                $"Config: {ConfigReader.ConfigFile}";
        }

        // ── Grid events ───────────────────────────────────────────────────────

        private void GridSelectionChanged(object? sender, EventArgs e)
        {
            if (_grid.SelectedRows.Count == 0) { _txtError.Text = ""; return; }
            var r = _grid.SelectedRows[0].Tag as LoadResult;
            if (r == null) { _txtError.Text = ""; return; }

            _txtError.Text = r.Status switch {
                LoadStatus.OK       => $"OK  —  {r.Path}\r\nLoaded in {r.Duration.TotalMilliseconds:0} ms",
                LoadStatus.Failed   => $"FAILED  —  {r.Path}\r\n\r\n{r.ErrorMessage}",
                LoadStatus.NotFound => $"NOT FOUND  —  {r.Path}\r\n\r\nCheck that the path in LoaderConfig.txt is correct.",
                LoadStatus.Skipped  => $"SKIPPED  —  {r.Path}\r\n\r\n{r.ErrorMessage}",
                _                   => "",
            };
        }

        private void GridCellFormatting(object? sender, DataGridViewCellFormattingEventArgs e)
        {
            if (e.RowIndex < 0 || e.RowIndex >= _grid.Rows.Count) return;
            var r = _grid.Rows[e.RowIndex].Tag as LoadResult;
            if (r == null) return;

            Color fg = r.Status switch {
                LoadStatus.OK       => ColOk,
                LoadStatus.Failed   => ColFail,
                LoadStatus.NotFound => ColMiss,
                LoadStatus.Skipped  => ColSkip,
                _                   => ColText,
            };

            // Colour the Status column strongly, dim the rest slightly
            if (e.ColumnIndex == 0)
                e.CellStyle.ForeColor = fg;
            else if (r.Status != LoadStatus.OK)
                e.CellStyle.ForeColor = Color.FromArgb(
                    (fg.R + ColText.R) / 2,
                    (fg.G + ColText.G) / 2,
                    (fg.B + ColText.B) / 2);
        }

        // ── Actions ───────────────────────────────────────────────────────────

        private void CopyReport()
        {
            try
            {
                Clipboard.SetText(LoadSession.BuildTextReport());
                MessageBox.Show("Report copied to clipboard.", "LispLoaderExtra",
                    MessageBoxButtons.OK, MessageBoxIcon.Information);
            }
            catch { }
        }

        private void OpenLog()
        {
            string log = Path.Combine(LogManager.LogFolder, "LispLoaderExtra.log");
            if (File.Exists(log))
                Process.Start("notepad.exe", log);
            else
                MessageBox.Show($"Log file not found:\n{log}", "LispLoaderExtra",
                    MessageBoxButtons.OK, MessageBoxIcon.Warning);
        }

        // ── Helpers ───────────────────────────────────────────────────────────

        private void AddCol(string header, int width, bool fill)
        {
            var c = new DataGridViewTextBoxColumn {
                HeaderText  = header,
                Width       = width,
                AutoSizeMode = fill
                    ? DataGridViewAutoSizeColumnMode.Fill
                    : DataGridViewAutoSizeColumnMode.None,
                SortMode    = DataGridViewColumnSortMode.Automatic,
                Resizable   = DataGridViewTriState.True,
            };
            _grid.Columns.Add(c);
        }

        private static Label MakeLabel(string text, float size, bool bold = false) =>
            new Label {
                Text      = text,
                Font      = new Font("Segoe UI", size,
                                bold ? FontStyle.Bold : FontStyle.Regular),
                ForeColor = ColText,
                BackColor = Color.Transparent,
                AutoSize  = false,
            };

        private static Button MakeFilterBtn(string text, int _) =>
            new Button {
                Text      = text,
                Size      = new Size(72, 28),
                FlatStyle = FlatStyle.Flat,
                BackColor = Color.FromArgb(50, 50, 60),
                ForeColor = ColText,
                Font      = new Font("Segoe UI", 8.5f),
                Cursor    = Cursors.Hand,
                FlatAppearance = { BorderColor = Color.FromArgb(70,70,80), BorderSize = 1 },
            };

        private static Button MakeActionBtn(string text, Color bg) =>
            new Button {
                Text      = text,
                Size      = new Size(110, 28),
                FlatStyle = FlatStyle.Flat,
                BackColor = Color.FromArgb(bg.R / 2, bg.G / 2, bg.B / 2),
                ForeColor = ColText,
                Font      = new Font("Segoe UI", 8.5f),
                Cursor    = Cursors.Hand,
                FlatAppearance = { BorderColor = bg, BorderSize = 1 },
            };

        private static string StatusLabel(LoadStatus s) => s switch {
            LoadStatus.OK       => "OK",
            LoadStatus.Failed   => "FAIL",
            LoadStatus.NotFound => "MISSING",
            LoadStatus.Skipped  => "SKIP",
            _                   => "?",
        };
    }
}


// ===== FILE: ScannedFile.cs =====
using System;

namespace LispLoaderExtra
{
    /// <summary>
    /// One file discovered by the disk scanner.
    /// This is the pre-load data model (before any load attempt).
    /// </summary>
    internal sealed class ScannedFile
    {
        internal int    RowIndex    { get; set; }       // display #
        internal string Category   { get; }             // "AutoCAD" | "Civil 3D"
        internal string MenuName   { get; }             // e.g. "3D_Menu", "Alignment_menu"
        internal string FileName   { get; }             // e.g. "QuickMirror.lsp"
        internal string Extension  { get; }             // ".lsp" | ".vlx" | ".fas" | ".dll"
        internal string FullPath   { get; }
        internal bool   Checked    { get; set; } = true;

        // Set after a load attempt
        internal LoadResult? LastResult { get; set; }

        internal string TypeLabel =>
            Extension.TrimStart('.').ToUpperInvariant();

        internal ScannedFile(
            string category, string menuName,
            string fileName, string extension, string fullPath)
        {
            Category  = category;
            MenuName  = menuName;
            FileName  = fileName;
            Extension = extension.ToLowerInvariant();
            FullPath  = fullPath;
        }
    }
}


// ===== FILE: LispLoaderExtra.cs =====
using System;
using System.IO;
using Autodesk.AutoCAD.Runtime;

[assembly: ExtensionApplication(typeof(LispLoaderExtra.LispLoaderExtraApp))]

namespace LispLoaderExtra
{
    /// <summary>
    /// Plugin entry point — loaded once via _.netload.
    ///
    /// Initialize() does nothing except:
    ///   1. Print the version banner to the AutoCAD command line + log
    ///   2. Ensure the log folder exists
    ///   3. Tell the user which commands are available
    ///
    /// NO files are auto-loaded. The user opens the window and decides.
    ///
    /// Commands registered by ReportCommand.cs:
    ///   LISPLOADEXTRA   — opens the loader window (scan + checkbox + load)
    ///   LISPLOADREPORT  — opens the report window (last session results)
    /// </summary>
    public class LispLoaderExtraApp : IExtensionApplication
    {
        private const string Source = "LispLoaderExtra";

        public void Initialize()
        {
            try
            {
                // Ensure log folder exists so LogManager can write immediately
                Directory.CreateDirectory(LogManager.LogFolder);
            }
            catch { }

            // Version banner
            VersionStamp.Print();

            // Commands hint
            LogManager.Info(Source, "Ready.  Type:");
            LogManager.Info(Source, "   LISPLOADEXTRA   → open loader window");
            LogManager.Info(Source, "   LISPLOADREPORT  → open last-session report");
            LogManager.Separator();
        }

        public void Terminate()
        {
            LogManager.Info(Source, "LispLoaderExtra unloaded.");
        }
    }
}


// ===== FILE: LogManager.cs =====
using System;
using System.Collections.Generic;
using System.IO;
using Autodesk.AutoCAD.ApplicationServices;
using Autodesk.AutoCAD.EditorInput;

namespace LispLoaderExtra
{
    internal enum LogLevel { INFO, WARN, ERROR }

    /// <summary>
    /// Writes timestamped log lines to:
    ///   1. The AutoCAD command line
    ///   2. The persistent .log file on disk
    ///   3. An in-memory ring-buffer (last 2000 lines) for the live log panel
    ///
    /// Format:  HH:mm:ss  [LEVEL]  [Source]  message
    /// Example: 05:29:43  [INFO ]  [PvSplitApi]  SplitDataLines.Add(…)
    ///
    /// Subscribers (e.g. LoaderWindow log panel) register via LogManager.Subscribe().
    /// Log file rotates to .bak.log at 5 MB.
    /// </summary>
    internal static class LogManager
    {
        // ── Paths ─────────────────────────────────────────────────────────────
        internal static readonly string LogFolder =
            @"C:\Users\mateid\OneDrive - DB E.C.O. Group\@C3D\@Dan_Templates\Acad\Support_files\Lisps\Help_File\Lisp_menu\LispLoaderExtra\ss";

        private static readonly string LogFile =
            Path.Combine(LogFolder, "LispLoaderExtra.log");

        private const long MaxLogBytes = 5 * 1024 * 1024;   // 5 MB

        // ── In-memory ring-buffer (for live log panel) ─────────────────────
        private const int RingSize = 2000;
        private static readonly Queue<string> _ring = new Queue<string>(RingSize);
        private static readonly object _ringLock = new object();

        // ── Subscriber callbacks ───────────────────────────────────────────
        // The log panel in LoaderWindow subscribes here.
        private static event Action<string>? _lineAdded;

        internal static void Subscribe(Action<string> handler)
        {
            lock (_ringLock)
                _lineAdded += handler;
        }

        internal static void Unsubscribe(Action<string> handler)
        {
            lock (_ringLock)
                _lineAdded -= handler;
        }

        /// <summary>Returns a snapshot of the in-memory log (oldest first).</summary>
        internal static string[] GetRingSnapshot()
        {
            lock (_ringLock)
                return _ring.ToArray();
        }

        // ── Public API ────────────────────────────────────────────────────────
        internal static void Info (string source, string message) => Write(LogLevel.INFO,  source, message);
        internal static void Warn (string source, string message) => Write(LogLevel.WARN,  source, message);
        internal static void Error(string source, string message) => Write(LogLevel.ERROR, source, message);
        internal static void Separator() => Write(null, null, new string('─', 72));

        // ── Core ──────────────────────────────────────────────────────────────
        private static void Write(LogLevel? level, string? source, string message)
        {
            string line = Format(level, source, message);

            // 1. AutoCAD command line
            try
            {
                Document? doc = Application.DocumentManager?.MdiActiveDocument;
                doc?.Editor?.WriteMessage("\n" + line);
            }
            catch { }

            // 2. Disk — ensure folder exists first
            try
            {
                Directory.CreateDirectory(LogFolder);
                RotateIfNeeded();
                File.AppendAllText(LogFile, line + Environment.NewLine);
            }
            catch { }

            // 3. In-memory ring + subscriber notification
            Action<string>? notify = null;
            lock (_ringLock)
            {
                if (_ring.Count >= RingSize) _ring.Dequeue();
                _ring.Enqueue(line);
                notify = _lineAdded;
            }

            // Fire subscribers outside the lock so they can call back into LogManager
            try { notify?.Invoke(line); }
            catch { }
        }

        internal static string Format(LogLevel? level, string? source, string message)
        {
            string ts  = DateTime.Now.ToString("HH:mm:ss");
            string lvl = level.HasValue ? $"[{level.Value,-5}]" : "       ";
            string src = source != null ? $"[{source}]" : string.Empty;
            return $"{ts}  {lvl}  {src,-22}  {message}";
        }

        private static void RotateIfNeeded()
        {
            if (!File.Exists(LogFile)) return;
            if (new FileInfo(LogFile).Length < MaxLogBytes) return;
            string bak = Path.ChangeExtension(LogFile, ".bak.log");
            if (File.Exists(bak)) File.Delete(bak);
            File.Move(LogFile, bak);
        }
    }
}


// ===== FILE: ReportCommand.cs =====
using System;
using System.Linq;
using System.Reflection;
using System.Text;
using System.Windows.Forms;
using Autodesk.AutoCAD.Runtime;

namespace LispLoaderExtra
{
    /// <summary>
    /// AutoCAD commands:
    ///   LISPLOADEXTRA   — open the loader window (modeless: stays open while you work)
    ///   LISPLOADREPORT  — open the report window (last session)
    ///   LISPLOADDIAG    — dump acmgd/accoremgd type names to log (debug)
    /// </summary>
    public static class ReportCommand
    {
        // Keep a single modeless instance alive so AutoCAD can continue working
        // while the form is open.  ShowDialog() blocks the ACAD command thread;
        // Show() does not — but it requires a message pump, which the Session
        // CommandFlags flag provides.
        private static LoaderWindow? _loaderInstance;

        [CommandMethod("LISPLOADEXTRA", CommandFlags.Session)]
        public static void ShowLoader()
        {
            System.Windows.Forms.Application.EnableVisualStyles();

            // If already open, bring it to front instead of opening a second copy
            if (_loaderInstance != null && !_loaderInstance.IsDisposed)
            {
                _loaderInstance.BringToFront();
                _loaderInstance.Activate();
                return;
            }

            _loaderInstance = new LoaderWindow();
            // Show() is modeless — AutoCAD keeps its message pump running,
            // so the form stays responsive and files load immediately.
            // We pass IntPtr.Zero so no parent window is set; the form floats
            // above AutoCAD via TopMost=true on its own.
            _loaderInstance.Show(new Win32Window(
                Autodesk.AutoCAD.ApplicationServices.Application.MainWindow.Handle));
        }

        [CommandMethod("LISPLOADREPORT", CommandFlags.Session)]
        public static void ShowReport()
        {
            System.Windows.Forms.Application.EnableVisualStyles();
            using var win = new ReportWindow();
            win.ShowDialog();
        }

        /// <summary>
        /// Diagnostic — type LISPLOADDIAG once after installing on a new
        /// AutoCAD version.
        /// </summary>
        [CommandMethod("LISPLOADDIAG", CommandFlags.Session)]
        public static void Diagnose()
        {
            const string Src = "LISPLOADDIAG";
            LogManager.Separator();
            LogManager.Info(Src, "Scanning ALL loaded assemblies for LISP-related methods...");

            int found = 0;
            string[] keywords = { "acedInvoke", "acedEval", "RunLisp", "LispInvoke", "EvalLisp" };

            foreach (Assembly asm in AppDomain.CurrentDomain.GetAssemblies())
            {
                string asmName = asm.GetName().Name ?? "";

                Type[] types;
                try { types = asm.GetTypes(); }
                catch { continue; }

                foreach (Type t in types)
                {
                    MethodInfo[] methods;
                    try
                    {
                        methods = t.GetMethods(
                            BindingFlags.Public | BindingFlags.NonPublic |
                            BindingFlags.Static | BindingFlags.Instance);
                    }
                    catch { continue; }

                    foreach (var m in methods)
                    {
                        bool match = false;
                        foreach (string kw in keywords)
                            if (m.Name.IndexOf(kw, StringComparison.OrdinalIgnoreCase) >= 0)
                            { match = true; break; }
                        if (!match) continue;

                        string sig = string.Join(", ",
                            System.Linq.Enumerable.Select(
                                m.GetParameters(),
                                p => p.ParameterType.Name + " " + p.Name));
                        LogManager.Info(Src,
                            $"[{asmName}] {t.FullName}.{m.Name}({sig})");
                        found++;
                    }
                }
            }

            try
            {
                using var rb = new Autodesk.AutoCAD.DatabaseServices.ResultBuffer(
                    new Autodesk.AutoCAD.DatabaseServices.TypedValue(5016),
                    new Autodesk.AutoCAD.DatabaseServices.TypedValue(5017));
                IntPtr ptr = rb.UnmanagedObject;
                LogManager.Info(Src, $"ResultBuffer.UnmanagedObject OK: 0x{ptr:X}");
            }
            catch (System.Exception ex)
            {
                LogManager.Warn(Src, "ResultBuffer.UnmanagedObject failed: " + ex.Message);
            }

            LogManager.Separator();
            LogManager.Info(Src, $"Total LISP methods found: {found}");
            LogManager.Separator();

            MessageBox.Show(
                $"Found {found} LISP-related method(s).\n" +
                $"Check log:\n{System.IO.Path.Combine(LogManager.LogFolder, "LispLoaderExtra.log")}",
                "LISPLOADDIAG",
                MessageBoxButtons.OK,
                found > 0 ? MessageBoxIcon.Information : MessageBoxIcon.Warning);
        }
    }

    /// <summary>
    /// Wraps an HWND so it can be passed to Form.Show(IWin32Window).
    /// This makes the WinForms form a child of the AutoCAD main window
    /// in the Windows Z-order, so it stays above AutoCAD without being
    /// on top of every other application.
    /// </summary>
    internal sealed class Win32Window : IWin32Window
    {
        public Win32Window(IntPtr handle) { Handle = handle; }
        public IntPtr Handle { get; }
    }
}
